Product Details
Condition: | New | Application: | Bottle | Plastic Processed: | PET |
Blow Moulding Type: | Stretch Blow Moulding | Automatic: | Yes | Place of Origin: | Jiangsu, China |
Brand Name: | Eceng | Model Number: | YC-5l-1 | Voltage: | Customer |
Power(W): | 16kw | Dimension(L*W*H): | 1.45*0.65*1.15(m) | Weight: | 700kg |
Certification: | CE ISO SGS | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Semic-automatic pet bottle blowing machine
Features
1.Stable performance with Advanced PLC
2.Conveying performs automatically with conveyor.
3.Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
4.High adjustability to enable the preheater to preheat performs in shapes by adjusting the light tube and the length of the reflecting board in the preheating area,and eternal temperature in the preheater with an automatic thermostatic apparatus.
5.Optimization of the oven,suction and convulsion devices,cool the preform surface.Waterway,air duct directly through the device,double protect the screw neck
6.Each mechanical action has safety self-locking device,whe a process fails, the program will automatically switch to the security status.
7.Servo device for the material transfer and bottle perform distribution, fast,reliable,and high stability.
8.Using high pressure and hyperbolic arm connecting rod clamping,strong clamping force,speed and distance of clamp open are adjustable.
9.Safe,reliable,and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
10.Along with remotemaintenance systems,remote inspection maintenance,solve the troubles for you.
11.Low rejection rete: less than 0.5 percent.
MODE:YC-5L-1
Main machine | Model Type | Parameter |
Product Spec | Max. product volume(L/cav) | 5.5L/cav |
Max. preform neck size(mm) | 150 | |
Max. product diameter(mm) | 200 | |
Max. product height(mm) | 400 | |
Cavities | 1 | |
Blow machine | Die force (KN) | 120 |
Die stroke (mm) | 320 | |
Max. mould size(mm) | 390*350 | |
Mould thickness | Adjustable | |
Mould spacing(mm) |
| |
Max. pulling stroke(mm) | 500 | |
Operation pressure(Mpa) | 0.8-1.0 | |
Operation air consumption (1tr/min) | 350 | |
Blow pressure(Mpa) | 1.2-2.8 | |
Blow air consumption (1tr/min) | 300 | |
Output(pcs/h) | 600-800 | |
Machine size(LxWxH)(m) | 1.56*0.7*1.9 | |
Machine weight(KG) | 700 | |
Oven | Temperature grade(rate) | 8 |
Heating time(S) | 90-200 | |
Voltage(V) | 220 or as your request | |
Frequency(HZ) | 50/60 | |
Total power(KW) | 16 | |
Oven Size (LxWxH | 1.45*0.65*1.15 | |
Oven weight (KG) | 330 |
Semi-automatic pet bottle blowing making machine
l Use integated mic computer controler,with OMRON control chip,the response speed is very quickly and the timing very precisely.Use life durable and failture rate very low.It’s the revolutionary product of industrial control.
l High responsiveness pneumatic components,action timely and precisely
l Thorough safe operation mechanism,start-up with two hands,avoid the accident during the operation
l Infrarted heating technology,safe and energy conservation,no pollution of the environment.With the 8 rates adjustable temperature controler,make the temperature suitable for blowing.
Our company specializes in manufacturing plastic machinery and moulds. We are mainly engaged in making automatic PET blow mould machine, semi-automatic PET blow machine, PE/PP/PVE/HDPE extruding blowing machine, injection machine and all kinds of moulds.
We have been committed to the design of plastic bottle making machine, especially the fully-automatic PET blow mould machine, from 300ml- 20L. Our machine complying with CE certification has good quality with praise by our customer
Service:
Provide whole drawing for the perform mould and bottle mould. Free charge for word design on the mould. We can help you install the machine; from setting machine, testing, and to check the machine is on the good working condition. There is a litter charge, only for flight charge and accommodation
We have rich experience in machine manufacturing quality inspection and after-sales service
With many whole production line experience and good understanding of chinese industry
We can give you the right equipment you are lokking for,no matter in price or reliability
All staff member work hard for just one goal satifying our customers with our best products and making you life better
