Glass Bottle Monoblock Sparkling Wine Filling Machine

Name: Glass Bottle Monoblock Sparkling Wine Filling Machine
Brand: Eceng
SKU: 121503725

US$ 10,000 - 150,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Eceng

Model Number:

CGF32-32-10

Zhangjiagang Eceng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOBSHANGHAI/NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Eceng

Model Number CGF32-32-10

Specifications

1.capacity:2000-20000bph
ntroler:PLC touch screen
3.certificate:CE
4.bottle:glass,PET

wine filling and capping machine

Specification of wine whisky Vodka filling machine as follows

Item	Subject	Parameter	Parameter
1	Model	CGF24-8F	CGF24-24-8F
2	Name	Filling capping two-in-one	washing filling capping three in one
3	Washing head	/	24heads
4	Filling head	24heads	24heads
5	Sealing head	8heads	8heads
6	Productivity	6000bph-8000bph	6000bph-8000bph
7	Motor power	3kw	4kw
8	Overall size	250018502400	400018502400mm
9	Weight	3T	4.5T
10	Applicable bottle size	glass bottle Diameter:50-92mm Bottle height:150~340mm volume: 350~2000ml	glass bottle Diameter:50-92mm Bottle height:150~340mm volume: 350~2000ml
11	Applicable cap	Aluminum and crown	Aluminum or crown
12	Timing type	Transducer	Transducer
13	Cap settling motor power	0.37kw	0.37Kw
14	Water pressure for washing		>0.06Mpa <0.2Mpa
14	Washing time		2sec
16	Washing drop dryer time:3.4sec		3.4sec
17	Valve space between		104.72mm
18	Pressure of washing		0.25-0.3Mpa
19	Filling temperature	0-4°C	0-4°C
20	Compress air wastage	20NM³/hour	20NM³/hour
