Single Phase alternator/Double bearing alternator 81.3KVA/81.3KW Stanford Type brushless AC alternator
The Alternator is dynamically balanced , brushless type, screen protected, revolving field,self excited,
self regulated through an AVR.
♥ Features:
1 Any permanent magnetic alternators,providing invariable excitation on all occasions.
2 Easy to be connected with power network or other alternators.
3 Standard 2/3 pitch windings check excessive midline current.
4 Balanced rotor with single or two sealed ball bearings.
5 Convenient installation and maintenance with easy access to terminals,rotating diodes and coupling bolts.
6 Wide range of flange adaptor and single bearing coupling disc
7 Meet leading standards.
♣81.3KVA/81.3KW Stanford Type 100%output brushless AC alternator
Brushless AC Generator | |||
Output Type |
AC SinglePhase |
||
Rated Power |
81.3KW |
Rated Capacity |
81.3KVA |
Frequency |
50HZ |
Speed |
1500RPM |
Voltage |
190V-440V |
Ingress Protection |
IP23 |
AVR |
SX440 |
Power Factor |
0.8 |
Port of loading |
Shanghai |
Warranty |
one year |
♥ Information for AVR:
We have many types of AVR,such us SX460, SX440, SX421, MX341, MX321,etc.
♥ ELECTRIC FEATURES:
Insulation
Insulation class H
♥ Winings and electric features:
2/3pitch windings
2/3 pitch windings design can effectively eliminate the third harmonica wave(3rd,9th,15th)of the voltage,
which is the best design of UPS for nonlinear load.
♥ Phone interference:
THF (defined by 40th part of BS4999)<=2%
TIF(defined by ASAC50.12)<=50.
♥ Radio interference:
Brushless apparatus and quality AVR ensure little radio interference in transmission.RFI noise filter is also avaiable.
♥ The advantage of our material:
· The rotors and stators with 100% copper wire.
· The enamelled wire is Essex by America.
· The silicon steel sheet we use is the products of Wugang Brand,800 Series.which is the most famous manufacture of steel.
And its advantage is its magnetic flux is large and its iron loss is small.
· The main frame of the alternator and lead box are made of steel,the end cover is made of high strength cast iron.
· All the components of our factory,the stator,rotor and excitation will be dipping lacquer twice.
· The rope of best nylon to be used in all the rotors and stators.
· The TWB bearings are useing in our products.
· All the rotors should be tested by dynamic balance of Germany to go on test of balance.
All the products should be tested by specialized Test Room.
The range of our products are from 6KW to 1000KW
