3g antenna booster
Electrical Specifications: | |
Specifications |
AC-GSM960 |
Frequency Range |
Uplink 885-915 Down930-960 |
Gain |
Uplink Gp≥45 Down Gp≥5 |
Output Power(dBm) |
≥23 ≥23 ≥20 |
Fluctuation band |
≤2dB |
Band rejection |
-60dB Bandwidth (BW-60dB) ≤ 42MHz |
-70dB Bandwidth (BW-70dB) ≤ 45MHz | |
Input / output impedance |
50Ω/N |
Input / output return loss |
≤-8dB |
Noise figure |
≤8dB |
Third-order intermodulation characteristics |
Po = 13dBm) |
|
In 9KHz ~ 1GHz range intermodulation ≤-30dBm Propagation Delay: ≤ 0.5μs | |
Propagation Delay |
≤ 0.5μs |
Ambient temperature |
-10 ℃ ~ 50 ℃ |
Power |
AC110 ~ 220V ± 10%?? 45 ~ 55Hz |
Dimensions |
148mm × 106mm × 33mm |
Reliability |
meet GB6993-86 standards |
Electromagnetic compatibility: | |
Compliance ETS300 694-4 standard Features |
a) light indicates power supply |
b) Output power light indicates | |
Coverage Area |
800 square meters |
Apply |
underground car park. public places. hotel. restaurant. supermarket. do indoor signal distribution. wireless coverage systems engineering |
Memo: Above specification subject to change without further notice.Please contact us for more details.
