door antenna
Applications:
900MHz RFID system
Wireless video transmission
Point to multipoint communication
Features:
* Low VSWR
* DC grounded
* Easy to mount
* Strong corrosion resistance
* Firm structure
* Vibration-proof and anti-impact
* Integral equipment cavity
Electrical Specifications | |
Model |
AC-D915W08 |
Frequency Range |
902-928MHz |
Band width |
26MHz |
Gain |
9dBi |
F/B Ratio |
≥20dB |
Horizontal Beam width |
60° |
Vertical Beam width |
70° |
V.S.W.R |
≤1.5 |
Radiation |
Direction |
Polarization |
Circular or Linear |
Maximum Input Power |
100W |
Impedance |
50ohm |
Operating Temperature |
-40℃ to+70℃ |
Connector |
N Female |
Cable Length |
/ |
Mount way |
Pole |
Mechanical Specifications | |
Antenna Dimension |
255x255x35mm |
Weight |
0.9KG |
Rated Wind Velocity |
241km/h |
Memo: Above specification subject to change without further notice.Please contact us for more details.
