2400/5800MHz dual-polarization outdoor 5.8ghz antenna
WiFi Flat Antenna 4 output
Dual Polarized Antenna
Panel Antenna
Electrical Specifications | |
Model |
AC-D2458W10X2 |
Frequency Range |
2400-2500/5150-5850MHz |
Gain |
10.5/13dBi |
VSWR |
≤1.8 |
Polarization |
Vertical |
Horizontal Beam Width |
65°/55° |
Vertical Beam Width |
30°/25° |
F/B Ratio |
>30dB |
Impedance |
50ohm |
Maximum Input Power |
100W |
Connector |
N×2 female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
250×250×25mm |
Weight |
1.2Kg |
Mounting Mast Diameter |
Ø30~Ø50mm |
Rated Wind Velocity |
241Km/h |
Memo: Above specification subject to change without further notice.Please contact us for more details.
