Antenna for Hyundai
antenna for hyundai
Applications:
GSM UNII / ISM system l
point to point on the multi-application
support IEEE802.11a/b/g
Features:
high gain and low VSWR with dual technology design
compact antenna structure, beautiful appearance for
indoor use, environmental adaptability wall mount
Electrical Specifications | |
Model |
AC-DGC-W07 |
Frequency Range |
800-960MHz |
Gain |
7dBi |
VSWR |
≤1.5 |
Polarization |
Vertical or Horizontal |
Horizontal Beamwidth |
70° |
Vertical Beamwidth |
55° |
Impedance |
50ohm |
Maximum Input Power |
50W |
Connector |
N Female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
140×120×40mm |
Weight |
500g |
Mounting Mast Diameter |
Ø30~Ø50 mm |
Rated Wind Velocity |
60s/h |
Memo: Above specification subject to change without further notice.Please contact us for more details.
