Help Center2 Ghz Dish Antenna GSM Parabolic Grid Antenna Long Distance
Related Products
Specifications
2 ghz dish antenna GSM parabolic grid Antenna long distance1.Freq:824-960MHz
2.Gain:18dBi
3.Size:1200mm
2 ghz dish antenna GSM parabolic grid Antenna long distance
Applications:
GSM/AMPS mobile communications system
Point to point or point to multipoint signal transmission
Repeater station
Long-distance communication
Wireless bridges
Features:
Welded Aluminum Grid
UV stable coat finish
Strong corrosion resistance and adaptability of environment
High gain, Low VSWR
Small size, Easy to mount
Electrical Specifications | |
Model |
AC-D90P12 |
Frequency Range |
824-960MHz |
Gain |
18dBi |
VSWR |
≤1.5 |
Polarization |
Vertical or Horizontal |
Horizontal Beamwidth |
16.5° |
Vertical Beamwidth |
16.5° |
F/B Ratio |
>30dB |
Impedance |
50ohm |
Maximum Input Power |
200W |
Connector |
N Female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
Φ1200mm |
Weight |
11Kg |
Mounting Mast Diameter |
Ø50~Ø75 mm |
Memo: Above specification subject to change without further notice.Please contact us for more details.
