Specifications
Antenna for gsm module gsm wireless networking equipment antena1.Freq:890-960/1710-1880MHz
2.Gain:5dBi
3.Size:29*230mm
Antenna for gsm module gsm wireless networking equipment antena
Applications:
Model units whip antenna is designed specifically
for mobile communications. Antenna made with stainless
steel spring wire, with good flexibility. The bottom of the
fixed magnetic disk mode or folders with optional side seat,
clip the tailstock and so on. According to the requirements
of the user configure different types of connectors
Features:
antenna, small size, light weight,
stable performance, reliable, easy to install
Electrical Specifications: | ||
Model |
AC-Q9018I16 |
AC-Q8019I16 |
Frequency Range |
890-960/1710-1880MHz |
824~896/1850-1990MHz |
Gain |
5dBi |
|
VSWR |
≤2.0 |
|
Polarization |
Vertical |
|
Impedance |
50ohm |
|
Maximum Input Power |
50W |
|
Cable type |
RG174 |
|
Length |
3M |
|
Connector |
SMA Male |
|
Operating Temperature |
-40℃ to+80℃ |
|
Mechanical Specifications: | ||
Antenna Dimension |
Φ29×230mm |
|
Weight |
80g |
|
Memo: Above specification subject to change without further notice.Please contact us for more details.
Our Factory:
Certificate:
The scene of HK global Sources exhibition :
Payment item and Delivery Ways:
