Specifications
GSM Repeater Booste UMTS Mobile Phone Signal Amplifier antenna1.Freq:824-960MHz
2.Gain:15dBi
3.Size:1250*180mm
GSM Repeater Booste UMTS Mobile Phone Signal Amplifier antenna
Applications:
800MHz / 800MHz band GSM900/IS95 mobile communication system
Multipoint repeater antenna system 900MHz RFID system
Features:
High gain, wide frequency band,
before and after the radiation ratio, anti-interference ability,
strong stainless steel structure is simple, easy to set up.
Electrical Specifications | |
Model |
AC-D90Y1210 |
Frequency Range |
824-960MHz |
Gain |
11/13/15dBi |
VSWR |
≤1.5 |
Polarization |
Vertical |
Horizontal Beamwidth |
36° |
Vertical Beamwidth |
32° |
F/B Ratio |
>18dB |
Impedance |
50ohm |
Maximum Input Power |
50W |
Connector |
N Female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
950/1100/1250×180mm |
Weight |
1.4Kg |
Mounting Mast Diameter |
Ø30~Ø50 mm |
