GPS GSM Wifi Combination Antenna Active roof Antenna
Applications:
Vehicle gps navigation
Features:
Work GPS Band High Gain, High Stability,
Light Weight, Compact Size UV-ABS Radome.
Electrical Specifications | |
GPS Part: | |
Model |
AC-GPS/GSM/WIFI-03 |
Center Frequency |
1575.42MHz |
Band width |
±5 MHz |
V.S.W.R |
1.5:1 |
Polarization |
RHCP |
Impendance |
50Ω |
LNA Gain |
28±2dB Typical |
Noise Figure |
1.5dB |
V.S.W.R |
<2.0 |
DC Voltage |
2.2-5.0V |
DC current |
5-15mA |
Cellular Part: | |
Frequency range |
824-960/1710-2170MHZ. |
VSWR |
2.0:1 |
Gain |
3dBi |
Polarization |
Linear |
Impendance |
50Ω |
WIFI Part: | |
Frequency range |
2.4/5GHZ |
VSWR |
2.0:1 |
Gain |
3dBi |
Polarization |
Linear |
Impendance |
50Ω |
Mechanical Specifications | |
Mounting Method |
Screw |
Housing |
Black |
Cable |
RG316/RG178/RG174/RG58U(can be customization) |
Length |
3M(can be customization) |
Connector |
SMA Male(can be customization) |
Operating Temperature |
-40°C~+85°C |
Humidity |
55%-75%RH |
Waterproof |
IP67 |
Humidity |
95%~100%RH |
Antenna Dimension |
143.6×65 mm |
Weight |
1.2KG |
Memo: Above specification subject to change without further notice.Please contact us for more details.
