Help CenterPowerful Amplified Yagi Antenna
Related Products
powerful amplified yagi antenna
Applications:
3G system
3G wireless access system
3G wireless data transmission
Country communication
Features:
High Gain, Low VSWR Stable Performance, Strong Adaptability of Environment
Electrical Specifications | |
Model |
AC-D8027Y17-12 |
Frequency Range |
806-960/1710-2170MHz |
Band width |
154/460MHz |
Gain |
17 dBi |
V.S.W.R |
≤1.5 |
F/B Ratio |
>18dB |
Horizontal Beamwidth |
30° |
Vertical Beamwidth |
30° |
Radiation |
Direction |
Polarization |
Vertical |
Maximum Input Power |
50W |
Impedance |
50ohm |
Operating Temperature |
-40℃ to+80℃ |
Connector |
N Female |
Cable Type |
RG58U |
Cable Length |
30cm |
Mount way |
Pole |
Mechanical Specifications | |
Antenna Dimension |
120x19x7cm |
Weight |
0.8 KG |
Memo: Above specification subject to change without further notice.Please contact us for more details.
