Help CenterWimax Antenna High Power Access Point
Related Products
Wimax antenna high power access point
Applications:
AMPS/GSM/DCS/UMTS/3G/800~2500MHz
Wall Mount,Indoor Used,Broadband Operation
Wall Mount,Indoor Used Compact Size, Low Profile
Features:
UNII ISM system
point-to-point
more applications for support.
Electrical Specifications | |
Model |
AC-D8025W07 |
Frequency Range |
800-960/1710-2500MHz |
Gain |
7/10dBi |
VSWR |
≤1.5 |
Polarization |
Vertical |
Horizontal Beamwidth |
70°/60° |
Vertical Beamwidth |
55°/45° |
F/B Ratio |
>20dB |
Impedance |
50ohm |
Maximum Input Power |
50W |
Cable type |
RG58U |
Length |
30CM |
Connector |
SMA Male |
Operating Temperature |
-40°C to+80°C |
Mechanical Specifications | |
Antenna Dimension |
207*180*43mm |
Weight |
500g |
Memo: Above specification subject to change without further notice.Please contact us for more details.
