315mhz 433mhz Whip Omni Terminal Uhf Vhf Small Sma Antenna
Specifications
315mhz 433mhz whip omni terminal uhf vhf small sma antenna1Frequency: 433/315MHz
2.Gain:2.5dBi
3.Antenna Size:8x50mm
315mhz 433mhz whip omni terminal uhf vhf small sma antenna
Applications:
AP Antenna is designed for 433MHZ as pread spectrum communication system.
After optimizing the design and tuning carefully, it has good VSWR.
The small dimension and light structure make it easy to install.
It also has good shockproof and anti-aging performance.
Electrical Specifications | ||
Model |
AC-Q433-53W |
AC-Q315-53W |
Frequency Range |
433±3MHz |
315±3MHz |
Gain |
2.5dBi |
|
VSWR |
≤2.0 |
|
Polarization |
Vertical |
|
Impedance |
50ohm |
|
Maximum Input Power |
50W |
|
Connector |
SMA Male |
|
Operating Temperature |
-40°C to+80°C |
|
Mechanical Specifications | ||
Antenna Dimension |
Φ8×50mm |
|
Weight |
15g |
|
