GSM Fiberglass Omni-directional Outdoor antenna
Applications:
AMPS800/GSM900
Application of multi-point repeater antennas
Features:
Product is a series of glass antenna, low loss,
high strength steel materials of high quality glass packaging,
radiator unit or units for the linear array, antenna power capacity,
voltage standing wave ratio, stable performance, easy installation,
wind, Waterproof, good corrosion resistance, is ideal for all kinds
of network communications required for the antenna.
Electrical Specifications | |
Model |
AC-Q90F10 |
Frequency Range |
824-896/806-960MHz |
Gain |
10dBi |
VSWR |
≤1.5 |
Polarization |
Vertical |
Horizontal Beamwidth |
360° |
Vertical Beamwidth |
10° |
Impedance |
50ohm |
Maximum Input Power |
50W |
Cable type |
RG58U |
Length |
30CM |
Connector |
N Female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
Φ38×1600mm |
Weight |
900g |
Mounting Mast Diameter |
Ø30~Ø50mm |
Memo: Above specification subject to change without further notice.
Please contact us for more details.
Our Factory:
Company Chart
Company Information
Asian Creation is a professional antenna designing and manufacturing factory Located in
FoShan City, Guang dong Province. We use our professional technique and best manufacturing technology to serve all of our customers.
Our main products include :
1. 2.4G/5G/3.5G WIFI WLAN WIMAX Antenna Series which include Omni Antenna, Grid Antenna, Yagi Antenna,Dish Antenna, Sector Antenna, Dual Polarized Antenna and 5.1-5.8GHz Broadband Antenna etc.
2. 3G/4G/LTE GSM/CDMA/LTE Antenna for outdoor or indoor Series
3.RFID Antenna,VHF/UHF Antenna,GPS Antenna etc
4. Relative Assemblies: Antenna Mounting Hardware, RF cable assembly, RF Connector ,
power splitters , couplers, surge protectors, etc.
Our Major Customers
Production Flow
Product Samples:
Certificate:
The scene of HK global Sources exhibition :
Payment item and Delivery Ways:
Warranty:
1. We can guarantee the product quality within 2 year(large antenna).
2.All of our products tested before delivery, If products cannot work,refund or exchange is available.
3.We provide comprehensive after-sales service, including quality service, guidance services,We focus on customer needs in every detail.Please contact us if you need our detail warranty term.
1.What's your MOQ?
We have no MOQ inquiry;
Samples ready in 2-3 days;
Order ready in 5-6days
2.How can we guarantee your products?
All items tested before shipping;
QC measures keep defect rates at < 0.01%
8 products lines tomeet your capacity requirements.
3.Do you offer OEM & 0DM ?
Yes,OEM/ODM antenna products specialist.
What is beneficial for you ?
1. Give you a profession wireless solution .
2. A full quotation as your required will be offered in 24 hours .
3. Samples will be delivered within 3 days .
4. 10-designers team-workers will give you ideas for your required products.
