ACS USB Android 13.56mhz acr122u nfc reader--ACR122U-A9
ACS USB Android 13.56mhz acr122u nfc reader--ACR122U-A9 General
ACR122 is a PC-linked contactless smart card reader/writer developed on the 13.56MHz Contactless (RFID) Technology and followed the ISO/IEC18092 Standard for Near Field Communication (NFC), supporting not only Mifare® ISO 14443 A and B cards but also NFC and FeliCa contactless technologies.
The ACR122 is a USB Plug and Play device with CCID compliance. By making use of up to 424 Kbps for NFC Tag access and full USB speed of up to 12 Mbps, the ACR122 can read and write faster and more efficiently. The proximity operating distance of ACR122 is up to 5 cm, depending on the type of contactless tag in use. Operating distance can be extended on request by adding an RF boaster, so the ACR122 is suitable for logistics and supply chain management.
In order to increase the security level, the ACR122 can be optionally integrated with an ISO7816-3 SAM slot. In addition, the ACR122 is available in module form for easy integration into bigger machines, like POS terminals, physical access devices and vending machines.
With excellent performance and flexibility, you can experience the convenience and benefits offered by the ACR122.
ACS USB Android 13.56mhz acr122u nfc reader--ACR122U-A9 Feature
Ÿ USB Full Speed (12 Mbps)
Ÿ USB PnP
Ÿ Bi-Color LED
Ÿ Built-in Antenna
Ÿ NFC Reader
Ÿ ISO/IEC18092 (NFC) compliant
Ÿ NFC Tags Access Speed = 424 kbps
Ÿ Contactless Smart Card Reader
Ÿ Support FeliCa card
Ÿ Support ISO 14443 Type A & B cards
- MIFARE® cards (Classics, DES Fire)
Ÿ CCID Standard
Ÿ CE and FCC Certificated
Ÿ RoHS Compliant
Ÿ User Controllable Buzzer (optional)
Ÿ SAM Socket (optional)
ACS USB Android 13.56mhz acr122u nfc reader--ACR122U-A9 Specification
Dimensions |
98 mm (L) x 65 mm (W) x 12.8 mm (H) |
Weight |
70 grams |
Interface |
USB Full Speed |
Operating Distance |
<= 50mm |
Supply Voltage |
Regulated 5V DC |
Supply Current |
200mA (operating); 50mA (standby); 100mA (normal) |
Operating Temperature |
0-50°C |
Operating Frequency |
13.56 MHz |
Standards/Certifications |
ISO14443 1-4, CE, FCC, RoHS Compliant |
Operating System Support |
Win98, Win ME, Win NT 4.0, Win 2000, Win 2003, Win 2003 R2, Win XP, Win Vista, Win 2008, Win 7, Win 8 Win 2003 x64, Win 2003 R2 x64, Win XP x64, Win Vista x64, Win 2008 x64, Win 2008 R2 x64, Win 7 x64, Win 8 x 64, Win 2012 x64 Windows CE 5.0 and 6.0 Mac Linux Android 3.1 and above |
ACS USB Android 13.56mhz acr122u nfc reader--ACR122U-A9 Application
Ÿ Home Banking and Home Shopping
Ÿ E-commerce
Ÿ Checking the balance of electronic purses
Ÿ Network access control
Ÿ Customer Loyalty Program
Ÿ Identification and Authentication
Ÿ Ticketing
Ÿ Online gaming
Ÿ Parking and toll collection
Ÿ Automatic Fare Collection
Ÿ Public Transportation Terminals
Ÿ Physical Access Control
Ÿ Time attendance
Ÿ Vending machines
Ÿ Contactless public phones
Ÿ Logistics and supply chain management
