Steel Wire Braided Hydraulic Hose

Steel Wire Braided Hydraulic Hose photo-1
Steel Wire Braided Hydraulic Hose photo-2
Steel Wire Braided Hydraulic Hose photo-3
Steel Wire Braided Hydraulic Hose photo-4
US$ 0.5 - 9.5 MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Sufeite
Model Number:
SAE100R2 A/DIN EN 853 2ST
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name Sufeite
Model Number SAE100R2 A/DIN EN 853 2ST

  Product Description





SAE 100 R2 A / DIN EN 853 2ST

Tube : Oil resistant synthetic rubber
Reinforceent : two high tensile steel wire layers 2 w
Cover : Abrasion and weather resistant synthetic rubber
Temperature range : -40 ℃ to +100 ℃

DN Hose I.D Wire O.D Hose O.D Working Pressure Burst Pressure Minimum Bend Radius Weight Length
inch mm mm mm MPa psi MPa psi mm kg/m metres
6 1/4 6.4 12.7 17.5 40.0 5800 160.0 22840 100 0.42 50/100
8 5/16 7.9 14.3 19.1 36.0 5250 140.0 20000 114 0.51 50/100
10 3/8 9.5 16.7 21.4 33.1 4800 132.0 18840 127 0.60 50/100
13 1/2 12.7 19.8 24.6 27.6 4000 110.0 15720 178 0.74 50/100
16 5/8 15.9 23.0 27.8 25.0 3630 100.0 14280 200 0.86 50/100
19 3/4 19.0 27.0 31.8 21.5 3120 85.0 12280 240 1.04 50/100
25 1 25.4 34.9 39.7 16.5 2400 65.0 9420 300 1.42 50
32 1 1/4 31.8 44.5 50.8 12.5 1820 50.0 7140 419 2.23 20 to 40
38 1 1/2 38.1 50.8 57.2 9.0 1310 36.0 5140 500 2.74 20 to 40
51 2 50.8 63.5 69.8 8.0 1160 32.0 4560 630 3.50 20 to 40



Company Information

Hengshui sufeite ture industry CO.LTD. is located in Hebei province Hengshui city Yongan Industrial Park, convenient transportation ,beautiful environment. Is the professional development of high pressure steel wire reinforced rubber hose assembly and the mechanism. The company covers an area of 25000 square meters,23000000 yuan in fixed assets, strong technical force, testing equipment, after sale service quality, and through ISO9001quality system certification.

The company has domestic and foreign advanced equipment and technology, strong sales and service team. The company can produce high pressure and ultra high pressure hose and assembly, the flame retardant and antistatic hose, engineering machinery hydraulic hose, temperature and cold resistant rubber hose, gas drainage hose, marine high pressure oil tube, oil drilling hose, various specifications of stainless steel bellows, metal hose, PTEE pipe. The company’s products throughout the country, and exported to Europe and the United States, the Middle East, South America and other countries, and long-term commitment to the OEM of big company production. productions are widely used in mining, petroleum, engineering machinery field, users get the praise.







Steel Wire Braided Hydraulic HoseSteel Wire Braided Hydraulic HoseSteel Wire Braided Hydraulic Hose



Steel Wire Braided Hydraulic Hose







Our factory,specialized in hydraulic rubber hose according to SAE AND DIN STANDARD.

Welcome to your inquiry,we would send you our best offer right away.
