Specifications
1)Low energy consumption2)Unique design,easily adjusted
3)Reasonable structure
2014 Supply inflatabl
2014 Supply inflatable and mechanical Ore Mining Flotation Machine for various ore
1. Application of flotation machine:
Hot sale flotation machine .This machine is used in copper,lead,zinc,nickel,molybdenum and so on non-ferrous metal,ferrous metal and non-ferrous metal mineral rough sizing,selection and counter-flotation process work.
2.Flotation machine working principle:
The impeller of the principal axis rotates by the driven of electric motor through the V-belt and then produces centrifugal function resulting in negative pressure.On one hand,it intakes enough air to mix with slurry.On the other hand,it mixers slurry and medicine,fine the foam in order that the mineral can stick on the foam,and then it turns into mineral foam after flotating on the slurry.Adjust the height of stopper to control fluid level in order that the available foam can be scrapped out by scrappers
3. Types of flotation machine:
We have various of flotation machine, such as SF0.37,SF0.7, SF1.2, SF2.8, XJK-0.13(1A),XJK-0.23(2A), XJK-0.35(3A), XJK-0.62(4A), XJK-1.1(5A), XJK-2.8(6A) etc.
4. Technical parameters of flotation machine:
SJK flotation machine
Model |
Volume |
Impeller dia(mm) |
Capacity(m3/min) |
Impeller speed(r/min) |
Scraper speed(r/min) |
Dimensions L*W*H(mm) |
Weight(t) |
XJK-0.13(1A) |
0.13 |
200 |
0.05-0.16 |
600 |
17.5 |
2100*865*900 |
0.35 |
XJK-0.23(2A) |
0.23 |
250 |
0.12-0.28 |
500 |
17.5 |
2625*1130*1290 |
0.41 |
XJK-0.35(3A ) |
0.35 |
300 |
0.15-0.5 |
470 |
17.5 |
3012*1350*1320 |
0.45 |
XJK-0.62(4A) |
0.62 |
350 |
0.3-0.9 |
400 |
26 |
3800*1500*1550 |
0.85 |
XJK-1.1(5A) |
1.1 |
500 |
0.6-1.6 |
330 |
26 |
4680*1820*1950 |
1.4 |
XJK-2.8(6A) |
2.8 |
600 |
1.5-3.5 |
280 |
26 |
7750*2600*2700 |
2.43 |
