Specifications
1.low cost,long life2.high efficiency&capacity
3.widely used in metallurgy,chemical,road construct
4.discharging evenly
Brief Introduction of How Hydraulic Cone Crusher Crushes
1. PYG series hydraulic cone crusher is the latest model of our company, which combines single cylinder cone crusher and PYF cone crusher.
2. It adopts a more advanced design concept. Better crushing frequency and uneven distance is used, so content of the fine grains is higher in crushing products.
3. Perfect combination of high performance crushing cavity and high crushing frequency improve its processing capacity greatly. And because of adopting laminated crushing principle, most of stone crushing machines are cubical shape.
Hydraulic Cone Crusher Advantages:
A. PYG Multi-cylinder hydraulic cone crusher adopts entirely hydraulic operation, which is easy to use and realize automation, so that its reliability and using life are improved greatly.
B. Simple structure is easy to operate and maintain, the adjustment of discharge opening is convenient and fast.
C. Especially, the lining plate is very easy to be replaced quickly, which reduces stoppage time.
D. Optimum design and hydraulic protection make it fewer breakdowns. Generally, its fault-free operation ratio can surpass 85%.
Technical Parameters & Hydraulic Cone Crusher Specification
| Specification | Model | Cavity | Large end diameter of crushing cone(mm) | Adjusting range of discharge opening(mm) | Feed opending size of open edge when recommending the min. discharge opening(mm) | Max. feeding size(mm) | Processing capacity(m³/h) | Main motor power(KW) | Dimensions(L×W×H) |
| Ø 900 | PYGB-0921 | Standard coarse type | 950 | 22-38 | 210 | 178 | 155-250 | 160 | 2007×2225×1950 |
| PYGD-0907 | Short head fine type | 8-25 | 70 | 60 | 80-220 | ||||
| PYGD-0909 | Short head medium type | 10-25 | 90 | 76 | 90-220 | ||||
| PYGD-0912 | Short head coarse type | 12-25 | 118 | 100 | 120-220 | ||||
| Ø1100 | PYGB-1121 | Standard medium type | 1100 | 20-45 | 211 | 180 | 200-445 | 220 | 2520×2620×2400 |
| PYGB-1124 | Standard coarse type | 26-45 | 235 | 200 | 230-445 | ||||
| PYGD-1107 | Short head fine type | 8-25 | 70 | 60 | 120-220 | ||||
| PYGD-1110 | Short head medium type | 12-25 | 96 | 82 | 120-220 | ||||
| PYGD-1112 | Short head coarse type | 14-25 | 124 | 105 | 120-220 | ||||
| Ø1400 | PYGB-1420 | Standard medium type | 1400 | 22-50 | 200 | 170 | 270-620 | 315 | 3106×3170×2945 |
| PYGB-1433 | Standard coarse type | 26-50 | 330 | 280 | 300-620 | ||||
| PYGD-1408 | Short head fine type | 8-25 | 80 | 68 | 115-370 | ||||
| PYGD-1411 | Short head medium type | 10-25 | 106 | 90 | 140-370 | ||||
| PYGD-1414 | Short head coarse type | 12-25 | 135 | 115 | 180-370 | ||||
| Ø1500 | PYGB-1522 | Standard medium type | 1500 | 25-50 | 223 | 190 | 365-725 | 400 | 3405×3480×3196 |
| PYGB-1534 | Standard coarse type | 32-50 | 335 | 285 | 405-725 | ||||
| PYGD-1509 | Short head fine type | 8-25 | 88 | 75 | 135-455 | ||||
| PYGD-1512 | Short head medium type | 10-25 | 124 | 105 | 175-455 | ||||
| PYGD-1515 | Short head coarse type | 13-25 | 152 | 130 | 225-455 |
