LIYU HC Series Cutting Plotter

LIYU HC Series Cutting Plotter thumbnail-1
LIYU HC Series Cutting Plotter photo-1
Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
LIYU
Model Number:
HC751/901/1201
Contact Supplier Request Quote Chat Now
Anhui Liyu Computer Equipment Manu. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any China sea&air port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name LIYU
Model Number HC751/901/1201
Voltage 110V/220V
Cache Capacity 64Mb
Paper Feed Width 860mm/1050mm/1350mm
Cutter Pressure 10g-400g
Cutting Width 760mm/950mm/1250mm
Cutting Speed 900mm/s
Driver Direct output from Corel Draw
Cutting Length more than 10m.
Repeat Cutting 0.1mm
Size 1.07X0.33X0.37m;1.29X0.33X0.37m;1.59X0.33X0.37m

Specifications

HC series Cutting Plotter:dual servo motor,900mm/s! CoutourCut Function,high-speed DSP remote control, more smooth curve cutting



Highlight feature for HC Cutting Plotter:





1. USB 2.0 interface, support hot-swappable, and is equipped with serial port to support the long-distance data transmission.

2. Digital force & speed adjustable, direct and steady.

3. Humane design, allows to adjust cutting force and speed while working.

4. LED assistant positioning enables easy contour cutting, more simple and convenient to use.

5. New high-speed DSP remote control system, the curve cutting is much smoother.

6. High-precision "steel barbed" axis, higher accuracy.

7. Dual high-precision DC servo motor, noise-free work.

8. High-strength aluminum alloy body, streamlined appearance, sturdiness and durability, beautiful and elegant.

9. Unique red cutting slot make it easier to operate.





MODEL

HC751

HC901

HC1201

Drive Motor

Dual Pittman DC Servo Motor

Media Size

860mm/2.82ft

1050mm/3.44ft

1350mm/4.43ft

Cutting Size

760mm/2.49ft

950mm/3.11ft

1250mm/4.10ft

Max.Cutting Speed

900mm/s

Cutting Force

10g-400g

LCD

With

Buffer capacity

64Mb

Resolution

0.025mm/step

Repeatability

0.1mm/0.0039in

Commands Set

HPGL or DMPL

Interfaces

USB & R232

Positioning Mode

Origin Setup and down available

Copy Function

Up to 99 copies

Power

<180W

Power requirements

AC220V/110V,50Hz~60Hz

Windows Driver

Direct Output from CorelDraw

Packing Size (WXDXH)

1.07X0.33X0.37m

 (3.51X1.08X1.21 ft)

1.29X0.33X0.37m

(4.23X1.08X1.21 ft)

1.59X0.33X0.37m

(5.21X1.08X1.21 ft)

G./Weight

20KG/45lbs

25KG/55lbs

39.0KG/86lbs

Environment

Temperature:035,  5%-95%Non-condensing
