2016 p5 led video wall price led wall pack 3d led wall panels pantallas de display
- 10000 Square Meter / Square Meters per Month
- SHEKOU PORT SHENZHEN
- T/T Credit Card PayPal
-
60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
-
80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
-
60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
-
2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
-
Led flood light, led Gas Station Lamp, LED canopy light 100w
-
120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | Ruisen | Model Number: | P5 |
| Usage: | Indoor | Tube Chip Color: | Other, RGB | Display Function: | Video |
| Pixels: | Other, 5mm | Screen Dimension: | 160*160mm |
Product Description
2016 p5 led video wall price led wall pack 3d led wall panels pantallas de display
Why Choose US
A: Support 24 Hours Online Guide & Help if you have any problems!
B: High quality original LED Chip with CE,ROHS,FCC certified.(Epistar)!
C: We gaurantee to test every part before the delivery and gaurantee the quality!
Model Number:
P2/P2.5/P3//P4//P5/P6/P7.62/P10
Die Casting Aluminum Rental Cabinet dimension:
480mm x 480mm
500mm x 500mm
512mm x 512mm
576mm x 576mm
640mm x 640mm
768mm x 768mm
800mm x 800mm
960mm x 960mm
Features:
1.Ultra-thin & ultra-light
2.Die casted AL cabinets, high precision with seamless splicing
3.Standard cabinet size: 500x500mm, convenient for area calculation
4.Highly effective & quick for transportation and screen assembling
5.SMD black light, wider viewing angle, high-contrast(5000:1),soft image
6.Special buckles structural connection between the cabinets,don’t need other tools
7.Cabinets are in common use for standard modules,shorten production cycle
Parameter:
| Pitch/mm | P3 | P4 | P5 | P6 |
| Module size/mm | 192x96 | 128x128 | 160x160 | 192x96 |
| Density of pixel/(dots/m2) | 111111 | 62500 | 40,000 | 27,777 |
| Pixel composition | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 |
| Led encapsulation | SMD2020 Black Lamps | SMD2020 | SMD3528 | SMD3528 |
| Black Lamps | White Lamps | White Lamps | ||
| Resolution of module | 63x32 | 32X32 | 32X32 | 32X16 |
| Optimum viewing distance | 3-10m | 4-15m | 6-16m | 7.5-20m |
| View angle / ° | 140H,120V | 140H,120V | 140 H,120 V | 140 H,120 V |
| Max power consumption/W/M2 | 1200 | 1,000 | 1,000 | 900 |
| Size of cabinet/mm | 576x576 | 512X512 | 640X640 | 768X768 |
| Resolution of cabinet | 192x192 | 128X128 | 128X128 | 128x128 |
| Driving method | 1/16 scan constant current | 1/16 scan constant current | 1/8 scan constant current | 1/8 scan constant current |
| Refresh rate Hz/S | More 600 | More 600 | More 600 | More 600 |
| Luminance of white balance | More 1500 nits | More 1500 nits | More 1500 nits | More 1500 nits |
| Thickness | 110mm | |||
| Operation of Environmental Temperature/°C | below 30 to above 50 | |||
| Working voltage | 110-220 VAC/+/- 10% | |||
| Grey scale/color | displaying colors≥16.7M(synchronized) | |||
| Brightness adjustment | 4096 levels of each color(manually),100 levels of each color(automatically) | |||
Control system linsn(sending card,receiving cards and Hubs)
Average of non-failure life >50,00h
Life span >100,000h
Functionless dot rate <0.0001
led matrix led video curtain flexible screen placa de video
1. We provide 2 years warranty. If the item is defective, please notify us within 7 days after goods delivered.
2. All items must be returned in their original condition, in order to qualify for a refund or exchange of goods.
3. The buyer is responsible for all shipping costs incurred.
1. How can i place an order?
Please inform your requirements as clear as possible. So we can send you the offer ASAP.it is better to contact us with Skype/email /phone within project begining, in case of any delays.
2. What kind of display we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display/stadium LED Display for you choose.
3. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days
4.How about the warranty ?
2 years warranty.
5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, etc. You can choose the one which is the most convenient or cost effective for you.
6. Order process
