Newest Product High Brightness P10 SMD Outdoor Full Color Led Display

Newest Product High Brightness P10 SMD Outdoor Full Color Led Display thumbnail-1
Newest Product High Brightness P10 SMD Outdoor Full Color Led Display photo-1
Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
PH12
Contact Supplier Request Quote Chat Now
Dongguan Asram Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number PH12
Usage Outdoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, 12mm
Screen Dimension Customized size

Specification:

Model

P12 Outdoor LED Display Screen

NO.

Items

Specifications

1

Pixel Pitch(MM)

12

2

Pixel Composition

SMD3in1

3

LED Encapsulation Type

SMD5050

4

LED Chip Sizes

12+13+13(RGB) Epistar + Silan + Nicha + Opto

5

Pixel Density(Dots/M2)

6944

6

Module Size(MM)

192 x 192

7

Module Resolution(Dots)

16 x 16

8

Cabinet Size(MM)

768 x 768

9

Cabinet Resolution(Dots)

64 x 64

10

Maximum Brightness

10000cd/sqm

11

Before Dot to Dot Correction

8000cd/sqm

12

After Dot to Dot Correction

7000cd/sqm

13

Brightness Adjustment Range

Manually, Auto Stepless Continuous Adjustment, 14 levels Adjustment without Gray Scale Loss

14

Color Temperature Adjustable

3200K - 10000K

15

Best View Distance(M)

12m - 85m

16

Horizontal View Angle

120 deg

17

Vertical View Angle

100 deg

18

Signal Processing

16bit

19

Control Mode

Synchronization

20

Driving Mode

Static Constant Current

21

Contrast

3000:1

22

Colors

549 Trillion Billion

23

Gray scale per color

26720 level

24

Video Frame Frequency

More than 60HZ

25

Refresh Rate

More than 3000HZ

26

Lifetime

100000 Hours

27

Maximum Power Consumption

Less than 800 w

28

Average Power Consumption

Less than 400 w

29

Cabinet Weight(without Steel Structure)

30 Kg

30

Compatible Signals( with video processor)

X Composite, X Component, RGB,SDI,HDSDI,DVI,AV, S-Video, VGA, HDMI, DP

31

Working Voltage

100-240V/AC 50/60HZ

32

Environment Temperature

–20 deg / +60 deg

33

Storage Temperature

–40 deg / +60 deg

34

IP Protection Rate

Front IP68, Rear IP65

35

Screen Surface Evenness

Less than 0.5mm

36

Working Humidity

10-99 percent

37

Storage Humidity

10-99 percent

38

Malfunction Dot Rate

Less than 0.0001

39

Display Screen Signals

RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION

40

Wind Resistance

Level 12

41

Shock Resistance

Level 8







System connection:



 newest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led display







Project Name: Outdoor led display project in Mongolia.


Product Name: PH10MM SMD


Pixel Pitch: 10 mm


Screen Size: 45 Sq.m


Installation Address: Mongolia


Installation Time: 2012





newest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led display





Project Name: Outdoor led display project in Canada.


Product Name: PH20MM SMD


Pixel Pitch: 20 mm


Screen Size: 84 Sq.m


Installation Address: Canada


Installation Time: 2010





 newest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led display











More types

 newest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led displaynewest product high brightness p10 SMD outdoor full color led display









Remarks







If you need some samples, please visit our Aliexpress store and buy them online.





Enjoy your shopping
