Home > Products > Full Color LED Display Screen > basketball playground board Sports perimeter LED signs module LED Sports playground cabinet board display screen panel sign
basketball playground board Sports perimeter LED signs module LED Sports playground cabinet board display screen panel sign
- 10000 Square Meter / Square Meters per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | OEM | Model Number: | PH10 |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | 10mm | Screen Dimension: | Customized size |
Product Description
Specification:
Model | P16 Outdoor LED Display Screen | |
NO. | Items | Specifications |
1 | Pixel Pitch(MM) | 16 |
2 | Pixel Composition | 1R1G1B or 2R1G1B |
3 | LED Encapsulation Type | DIP346 |
4 | LED Chip Sizes | 12+13+13(RGB) Epistar + Silan + Nicha + Opto |
5 | Pixel Density(Dots/M2) | 3906 |
6 | Module Size(MM) | 256 x 256 (256 x 128 is optional) |
7 | Module Resolution(Dots) | 16 x 16 (16 x 8 is optional) |
8 | Cabinet Size(MM) | 1024 x 768 |
9 | Cabinet Resolution(Dots) | 64 x 48 |
10 | Maximum Brightness | 12000cd/sqm |
11 | Before Dot to Dot Correction | 9000cd/sqm |
12 | After Dot to Dot Correction | 8000cd/sqm |
13 | Brightness Adjustment Range | Manually, Auto Stepless Continuous Adjustment, 14 levels Adjustment without Gray Scale Loss |
14 | Color Temperature Adjustable | 3200K - 10000K |
15 | Best View Distance(M) | 15m - 110m |
16 | Horizontal View Angle | 120 deg |
17 | Vertical View Angle | 60 deg |
18 | Signal Processing | 16bit |
19 | Control Mode | Synchronization |
20 | Driving Mode | Static Constant Current |
21 | Contrast | 3000:1 |
22 | Colors | 281 Trillion Billion |
23 | Gray scale per colors | 65536 level |
24 | Video Frame Frequency | More than 60HZ |
25 | Refresh Rate | More than 3000HZ |
26 | Lifetime | 100000 Hours |
27 | Maximum Power Consumption | 850 w |
28 | Average Power Consumption | 380 w |
29 | Cabinet Weight(without Steel Structure) | 30 Kg |
30 | Compatible Signals(with video processor) | X Composite, X Component, RGB,SDI,HDSDI,DVI,AV, S-Video, VGA, HDMI, DP |
31 | Working Voltage | 100-240V/AC 50/60HZ |
32 | Environment Temperature | –20 deg / +60 deg |
33 | Storage Temperature | –40 deg / +60 deg |
34 | IP Protection Rate | Front IP68, Rear IP65 |
35 | Screen Surface Evenness | Less than 0.5mm |
36 | Working Humidity | 10-99 percent |
37 | Storage Humidity | 10-99 percent |
38 | Malfunction Dot Rate | Less than 0.0001 |
39 | Display Screen Signals | RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION |
40 | Wind Resistance | Level 12 |
41 | Shock Resistance | Level 8 |
Project Name: outdoor led display project in Brazil.
Product Name: PH10MM DIP
Pixel Pitch: 10 mm
Screen Size: 76 Sq.m
Installation Address: Brazil
Installation Time: 2012
Project Name: outdoor led display project in Spain.
Product Name: PH16MM DIP
Pixel Pitch: 16 mm
Screen Size: 32 Sq.m
Installation Address: Spain
Installation Time: 2010
