Home > Consumer Electronics > LED Display > Indoor LED Display > Sports Entertainment Board Module Sports Entertainment LED Panel LED Sports Entertainment Board Module Display Screen Panel Sign

Sports Entertainment Board Module Sports Entertainment LED Panel LED Sports Entertainment Board Module Display Screen Panel Sign

Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

PH16

Contact Supplier Request Quote Chat Now

Dongguan Asram Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number PH16

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 16mm

Screen Dimension Customized size

Model	P16 Outdoor LED Display Screen
NO.	Items	Specifications
1	Pixel Pitch(MM)	16
2	Pixel Composition	1R1G1B or 2R1G1B
3	LED Encapsulation Type	DIP346
4	LED Chip Sizes	12+13+13(RGB) Epistar + Silan + Nicha + Opto
5	Pixel Density(Dots/M2)	3906
6	Module Size(MM)	256 x 256 (256 x 128 is optional)
7	Module Resolution(Dots)	16 x 16 (16 x 8 is optional)
8	Cabinet Size(MM)	1024 x 768
9	Cabinet Resolution(Dots)	64 x 48
10	Maximum Brightness	12000cd/sqm
11	Before Dot to Dot Correction	9000cd/sqm
12	After Dot to Dot Correction	8000cd/sqm
13	Brightness Adjustment Range	Manually, Auto Stepless Continuous Adjustment, 14 levels Adjustment without Gray Scale Loss
14	Color Temperature Adjustable	3200K - 10000K
15	Best View Distance(M)	15m - 110m
16	Horizontal View Angle	120 deg
17	Vertical View Angle	60 deg
18	Signal Processing	16bit
19	Control Mode	Synchronization
20	Driving Mode	Static Constant Current
21	Contrast	3000:1
22	Colors	281 Trillion Billion
23	Gray scale per colors	65536 level
24	Video Frame Frequency	More than 60HZ
25	Refresh Rate	More than 3000HZ
26	Lifetime	100000 Hours
27	Maximum Power Consumption	850 w
28	Average Power Consumption	380 w
29	Cabinet Weight(without Steel Structure)	30 Kg
30	Compatible Signals(with video processor)	X Composite, X Component, RGB,SDI,HDSDI,DVI,AV, S-Video, VGA, HDMI, DP
31	Working Voltage	100-240V/AC 50/60HZ
32	Environment Temperature	–20 deg / +60 deg
33	Storage Temperature	–40 deg / +60 deg
34	IP Protection Rate	Front IP68, Rear IP65
35	Screen Surface Evenness	Less than 0.5mm
36	Working Humidity	10-99 percent
37	Storage Humidity	10-99 percent
38	Malfunction Dot Rate	Less than 0.0001
39	Display Screen Signals	RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
40	Wind Resistance	Level 12
41	Shock Resistance	Level 8

System connection:

Project Name: Outdoor LED display in Brazil;

Product Model: PH16MM DIP;

Project Area: Brazil;

Screen Size: 120 sqm;

Applicable environment: Commercial LED display; Outddoor Video Advertising LED Display;

Time: 2012

Project Name: Outdoor roof top led display project in Libya.
Application Environment: Outdoor led advertising display, Outdoor roof Top led screen
Product Name: PH10MM DIP
Pixel Pitch: 10 mm
Screen Size: 8 Sq.m
Installation Address: Libya
Installation Time: 2012

Project Name: Outdoor Roof top led display project in Spain.
Application Environment: Outdoor led advertising display, Outdoor roof Top led screen
Product Name: PH10MM DIP
Pixel Pitch: 10 mm
Screen Size: 8 Sq.m
Installation Address: Spain
Installation Time: 2011
