Specifications
1.High Resolution2.High Brightness
3.ce,rohs,ul,fcc
4.Five years warranty
5.Low power consumption
Specification:
Product Name: P7.62 Indoor LED Display Screen
Product Type: Indoor
Pixel Pitch: 7.62mm
Pixel Configuration: 1R1G1B
Optimal Viewing Distance: 7m - 60m
Products function introduction:
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment;
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;
3) To pictures and character, have clear, exquisite and real display effect;
4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion;
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
Products Advantages:
1) Price Advantage: we have the best competitive price at the market; also have the same even better quality;
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each led lamps;
3) Quality advantage: From material to finished product, from design to produce, we control all steps that are the guarantee of the quality and reliability;
4) Service advantage: Better service at same situation, better cooperation at same service.
Products application area:
1) Full color LED display: Equally or compactly make the red, green, blue color in one dot, equally distribute at the panel, and so make the whole display
2). usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment, etc.
1 |
Cabinet size |
976mmW*976mmH*140mmT |
2 |
Cabinet Resolution |
128pixels *128 pixels |
3 |
Cabinet Weight |
About30KG |
4 |
Pixel density(dots/M2) |
17222dots/ m2 |
5 |
White Balance Brightness |
≥1600 (cd/m2) |
6 |
Brightness Adjusted |
256 grade automatically, 8 grade manually |
7 |
Color temperature(K) |
5000—9500 |
8 |
View Angle |
Horizontal:140°; Vertical:140° |
9 |
Best viewing distance(m) |
7—150 |
10 |
Communication distance |
120 meters by LAN cable(without relay)(optical fiber transmission 500M-10000M) |
11 |
Drive Method |
1/8 scran or 1/4 scan |
12 |
Gray Grades |
4096levels for each color |
13 |
Display Color |
68.7billion |
14 |
Refresh Frequency (Hz) |
≥4000-5000 |
15 |
Control Mode |
Synchronous with PC |
16 |
Signal interface |
DVI |
17 |
Input signal |
S-Video,Component,VGA,DVI, |
18 |
Display format |
1024 * 768, 1280*1024, 1600*1200, 1920*1280, |
19 |
Software |
Support windows series system |
20 |
Waterproof |
Yes |
21 |
Protection |
IP43 |
22 |
Working temperature(ºC) |
(-20°C~+60°C ) |
23 |
Humidity(RH) |
10%—90%RH |
24 |
LED Lifetime(hours) |
≥100,000 |
25 |
Whole Display Flatness |
Less than 1mm Juncture |
26 |
Power Consumption |
Average:≤450w/m2;Maximum: ≤1300 |
27 |
Operating Voltage |
AC100V±220V 50~60HZ |
28 |
Operating Platform |
WINDOWS(WIN98,WIN2000, WIN XP) |
System connection:
P6mm indoor led screen for meething
Project Name: Canada indoor LED Display;
Product Name: P5
Pixel Pitch: 5 mm
Screen Size: 15 Sq.m
Installation Address: Malmo, Sweden
Installation Time: May, 2009.
