Cellular Confinement Systerm HDPE Geocell
Product Description geocell
Geocell is honeycomb shaped structures, in material of HDPE, welded by highfrequency ultrasonic.
Being flexible, geocell can be folded in transit and outspreaded filling with sand, stone or concrete in
roadbed construction.
Specification
1.Height:50mm-200mm
2.Welding distance:330mm-1000mm
3.Thickness of sheet: 1.0mm-1.5mm
Technical Parameter geocell
Product Type |
Height (mm) |
Welding Distance (mm) |
Thickness (mm) |
Tensile Strength of Welding Points(N/cm) |
Tensile Strength of Connection of Cells(N/cm) |
Tensile Strength at Yield of Each Sheet(N/Mpa) |
Flat and Not Perforated |
50≤H≤250 |
330≤A≤1000 |
1.1/1.2 |
≥100 |
≥120 |
≥20 |
Flat and Perforated |
50≤H≤250 |
330≤A≤1000 |
1.1/1.2 |
≥100 |
≥120 |
≥20 |
Embossed and Not Perforated |
50≤H≤250 |
330≤A≤1000 |
1.5 |
≥100 |
≥120 |
≥20 |
Embossed and Perforated |
50≤H≤250 |
330≤A≤1000 |
1.5 |
≥100 |
≥120 |
≥20 |
|
Remarks:Width of the product can be made according to the customer’s demand, and the other special standards will be carried out by agreement or contact. | ||||||
Benefits hdpe geocell
1. Produces a stiff base with high flexural strength; acts like a semi rigid slab by distributing loads laterally.
2. Minimizes impact of differential and overall settlement even on low-strength subgrades.
3. Increases effective structural number, reducing fill depth requirement by 50%.
4. May allow use of poor-quality granular fills in place of more costly imported materials.
5. With permeable infill, reduces storm water runoff and effectively performs as an on-site storm water
retention/detention “basin” storage, reducing need and costs for storm water ponds.
Application
1.to stable the bed of railway and road
2.to bear the bed of road
3.to bear the loading dykes and walls
4.to administer shallow water and river
5.to support pipeline and sewer
6.to prevent landslide and to be used as compound walls to support loading
7.to be used in dependent walls,wharfs and bank and so on
8.to govern sand,beach,river bank and riverbed
