8MM Copper Rod Breakdown Machine or Copper Wire Drawing Machine With 13 Drawing Dies
US$ 150,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
ebp
Model Number:
LHD 450
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing shanghai Luzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aluminum Rod Breakdown Machine or Aluminum Wire Drawing Machine With 13 DiesUS$ 160,000 - 200,000MOQ: 1 Set -
8MM Copper Rod Breakdown Machine or Wire Drawing Machine With AnnealingUS$ 150,000 - 200,000MOQ: 1 Set
-
8MM Copper Rod Breakdown Machine or Copper Wire Drawing Machine LHD450US$ 150,000 - 200,000MOQ: 1 Set
-
Aluminum Rod Breakdown Machine or Aluminium Wire Drawing Machine With 13 Drawing DiesUS$ 110,000 - 150,000MOQ: 1 Set
-
Aluminum Wire Drawing Machine or Aluminum Rod Breakdown Machine With 9 Drawing Dies ;US$ 150,000 - 160,000MOQ: 1 Set
Place of Origin
Sichuan, China
Brand Name
ebp
Model Number
LHD 450
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
it is used for draw copper rods into wires with the diameter from 1.8mm to 4.5mm1 Inlet diameter 9.5mm pure aluminum
2 Outlet diameter 1.8~4.5mm
3 Max. delivery speed 25m/sec
4 Bobbin-change speed 6~12m/sec.
5 Max. number of drawing pass 13
6 Diameter of final capstan 450mm
7 Drawing capstan speed ratio 1.28~1.15
8 Take-up bobbin size PND500/630 or PND630/710
9 barrel diameter 315~355mm
10 Max. traverse width 460mm
11 Max. traverse pitch 6mm/r, stepless and adjustable
12 Noise from machine ≤85dB
13 Consumption of compressed air 6m3/hr., pressure at 0.5Mpa
14 Capacity of drawing oil tank 5.5m3
15 Main motor (DC) 250kW
16 Drive motor for final capstan (DC) 75kW
17 Take-up motor(DC) 2 sets 30kW
18 Total installed power 400kW
19 Overall dimension 18500x4000x4500mm
20 Total weight 31T
Product Description
