Aluminum Rod Breakdown Machine or Aluminum Wire Drawing Machine With 13 Dies
US$ 160,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
ebp
Model Number:
LHD 450/13P
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing shanghai Luzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
8MM Copper Rod Breakdown Machine or Wire Drawing Machine With AnnealingUS$ 150,000 - 200,000MOQ: 1 Set -
8MM Copper Rod Breakdown Machine or Copper Wire Drawing Machine LHD450US$ 150,000 - 200,000MOQ: 1 Set
-
Aluminum Rod Breakdown Machine or Aluminium Wire Drawing Machine With 13 Drawing DiesUS$ 110,000 - 150,000MOQ: 1 Set
-
Aluminum Wire Drawing Machine or Aluminum Rod Breakdown Machine With 9 Drawing Dies ;US$ 150,000 - 160,000MOQ: 1 Set
-
Aluminum Wire Drawing Machine or Aluminum Rod Breakdown MachineUS$ 150,000 - 160,000MOQ: 1 Set
Place of Origin
Sichuan, China
Brand Name
ebp
Model Number
LHD 450/13P
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
it is used to draw aluminum rod into wireswith the diameter from 1.8mm to 4.5mm
1 Inlet diameter 9.5mm pure aluminum
2 Outlet diameter 1.8~4.5mm
3 Max. delivery speed 25m/sec
4 Bobbin-change speed 6~12m/sec.
5 Max. number of drawing pass 13
6 Diameter of final capstan 450mm
7 Drawing capstan speed ratio 1.28~1.15
8 Take-up bobbin size PND500/630 or PND630/710
9 barrel diameter 315~355mm
10 Max. traverse width 460mm
11 Max. traverse pitch 6mm/r, stepless and adjustable
12 Noise from machine ≤85dB
13 Consumption of compressed air 6m3/hr., pressure at 0.5Mpa
14 Capacity of drawing oil tank 5.5m3
15 Main motor (DC) 250kW
16 Drive motor for final capstan (DC) 75kW
17 Take-up motor(DC) 2 sets 30kW
18 Total installed power 400kW
19 Overall dimension 18500x4000x4500mm
20 Total weight 31T
