Specifications
1.outdoor led display2.5500nit-7500nits
3.iron and aluminum
4.2 years warranty
Model: P16 outdoor full color screen,video wall,led billboard,led gaint TV for advertising,commercial board
P16-1R1G1B/2R1G1B
Haisheng
Outdoor full color led display products features:
1) Based on the customized design,our outdoor display can be custom-bulit into fit and size.They are ideal for entertainment,sports,advertising,concerts in both of rental and fixed installation.
2) The outdoor LED display is suitable for long viewing distance application.It includes P10,P12,P16,P20,and P25.
With our outdoor display you can get clearer resolved images,Colors are appeared brighter and contrast is more strengthen.
3] Outdoor advertising screen refers to the red, green and blue LED lights composition, white balance, and can display 16,777,216 colors are capable of real-time, simultaneous display of various information, such as two-dimensional or three-dimensional animation, video, TV, DVD and on-site a variety of live video content. Outdoor advertising display outdoor display of the most widely used one type, characterized by large angle, high brightness, colorful and attractive, long life and energy-saving and so on, the display can be synchronized with the computer display Chinese characters, English text and graphics; video display screen using micro-computer control, graphics, images, and Mao, to real-time, synchronization, clear message to the broadcast of a variety of information dissemination, but also shows two-dimensional, three-dimensional animation, video, TV, VCD programs and on-site live. LED screen display colorful, three-dimensional sense of strong, static, such as painting, moving, such as movies.
LED
|
| |
| led brand | opto and silan |
| red | 1100mcd/ 620nm-621nm |
| green | 2300mcd/520nm-521nm |
| blue | 500mcd/470nm-471nm |
Module
| |
| led module size | 256mm*128mm |
Moudle Resolution(W×H) |
16dotsl*8dots |
| drive mode | static scanning |
| pixel density | 3906dots/sq.m |
Cabinet
Technical Specification(P16mm):
| Display and control feature | Structure feature | ||
| Specification | Parameter | Specification | Parameter |
| Pixel Pitch | 16 mm | Module size | 256*128 |
| Pixel composing | 1R1G1B | Display resolution/module | 16 dots*8dots |
| Wavelength (R) | 620±1 | Standard cabinet size | 1024 mm*768 mm |
| Wavelength (G) | 520±1 | Weight per sqm | 65 Kg/sqm |
| Wavelength (B) | 470±1 | Protection classification | IP65 |
| Wave Angle (H) | 140°(H)/ 60° | Install mode | Wallmount, hung and stand structure |
| LED package | DIP 346 | Cabinet Material | Iron/Aluminum |
| Density per sqm | 10,000 pixel | Working power | |
| Display color | 256*256*256 | Specification | Parameter |
| Whiteness brightness | ≥5500 | Working voltage | AC 220v/380v±10% 47~64Hz |
| Brightness level | 128 grade | Max power/sqm | 750W/sqm |
| Changing frame frequency | 60 Hz | Average power/sqm | 400W/sqm |
| Refresh | 480 Hz | Short circuit protection | Yes |
| Driving method | 1/4 Constant Driving | Led Lamp type | Nichia/Cree/Axt/Silan/Taiwan |
| Control mode | synchronous | Working environment | |
| Display port | DVI | Specification | Parameter |
| Display mode | 1024*768 /1024*1024 | Environment | Outdoor |
| Out of control | 1/10,000 ( scattered) | Working temperature | --20~50 |
| lifetime | 100,000 hours | Working Humidity | 10~90% |
display aging and test
certification
our case
