Specifications
1.CE ROHS FCC2.waterproof ip65
3.high brightness
4.cabinet size 1000mmx1000mm
5.2 year waranty
Outdoor hd video ads P12.5 led panel full color Outdoor hd video ads P12.5 led panel full color
Sell points of product :
1. high definition
2. full color rgb dip
3. IP65 waterproof both front and rear
4. CE ROHS FCC ISO9001
5. good quality with cost effective price
Key point of Haisheng:
1. approved by alibaba and TUV supplier assessment
2.strict quality control from materials, production, test, package
3. technical support, including hardware and software
4. professional team at your service
5. 2 year guarantee + 1 set of spare part
Specification for your reference:
| Item | Specifications | |||||
| LED Lamps | Type | DIP(High Brightness LEDs) | ||||
| Arrangement | 1R,1G,1B | |||||
| Red Wavelength | 625nm(+2nm) | |||||
| Green Wavelength | 525nm(+2nm) | |||||
| Blue Wavelength | 475nm(+2nm) | |||||
| LED Module | Pixel Pitch | 12.5 mm | ||||
| Module Resolution | 16*16pixels | |||||
| Module Size | 200*200 mm | |||||
| LED Cabinet | Pixel Density | 6400 pixels/sq.m | ||||
| Cabinet Resolution | 80*80pixel | |||||
| Cabinet Dimension | 1000*1000mm | |||||
| Cabinets Material | Sealed Iron Cabinets | |||||
| Brightness | >6500cd/sq.m | |||||
| Viewing Angle | 110(Horizontal),55(Vertical) | |||||
| Best Viewing Distance | 12m~150m | |||||
| Power Consumption (Max) | 600 w/sq.m | |||||
| Power Consumption (Average) | 200 w/sq.m | |||||
| Weight | less than 65 Kgs/sq.m | |||||
| Frame Frequency | no less than 60 frame/sec | |||||
| Refresh Rate | no less than 480 HZ/sec | |||||
| Input Voltage | 220/110 VAC, 50/60 Hz | |||||
| Output Voltage | 5V,40A | |||||
| Grey Scale Levels | R(256bit) x G(256bit) x B(256bit) | |||||
| Color Processing | R(1024) x G(1024) x B(1024) | |||||
| Brightness Adjustment | 256 levels of each color(R,G,B) can be adjusted manually, and 8 levels of each color can be adjusted automatically |
|||||
| MTBF | 5000 hours | |||||
| Life-span | 100,000 hours | |||||
| Protection Level | Face:IP 65 | |||||
| Malfunction Dot Rate | less than 0.0001 | |||||
| Working Temperature | -20°C~65°C | |||||
| Humidity | 10%~99% | |||||
| Control System | Drive Mode | 1/4 scan | ||||
| Control Mode | Synchronization | |||||
| Control System | Synchronous control system | |||||
| Software | LED Studio (LINSN) | |||||
| Input Signal | RF,TV,S-VIDEO,PAL,DVI,HDTV,VGA,SDI,AVI,etc | |||||
| PC Operating system System | Microsoft Windows 98, 2000, XP, 7,8, and Vista | |||||
About Haisheng:
Shenzhen Haisheng Optoelectronic CO., LTD is a professional LED display, HSTV manufacturer.
It is a high technology which is specialized in researching, designing, manufacturing and exporting
all kind of LED products. We have our own professional R&D department, engineers, sales department,
experienced QC and workers.
Currently we design and produce our new type of products with patent right reserved, such as HSTV, double
sided led display, one whole body outdoor advertising led display, one whole body led window display.
We focus on looking for the best solution for every customer’s project and also glad to see that we receive good feedback
and win long term relationship. Win-win business is what we pursue all the time.
Basic promise from Haisheng:
A: Full automatic production to control our high quality, best color consistency and get better performance.
B: Energy saving, low power consumption and long lifespan 100,000 hours (about 10 years).
C: We guarantee that the equipment we provide are brand new, complete and unused.
D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
E: Our quality control throughout every process from materials-production- test-package-delivery(led lamp, module,
cabinet, led screen)
After sale service:
1) Guidance service: We can guide on line if customers have questions about the installation and usage.
For large project, we provide your engineer a week free training, or if customer could bear the relevant cost, our engineer can go to customer’s country for on-site guidance.
2) Warranty period: 2 years after shipment.
3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.
4) Maintenance terms: In the Maintenance period, free of all maintenance charges. Under normal use and storage, our company will be responsible for the equipments. If there is any failure in product quality, our company will maintain and change the components for free.After Maintenance period, only charge the material costs free of manual work fees.
Aging test in the factory:
Customers feedback:
package and shipping:
Thanks for the attention, enjoy your shopping :)
