Solar Irrigation Pump

Name: Solar Irrigation Pump
Brand: GreenAnswer
SKU: 121072979

US$ 10,000 - 50,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GreenAnswer

Model Number:

SP15K

Zhejiang Tianci New Energy Science & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GreenAnswer

Model Number SP15K

Specification Normal

Output Voltage (V) AC380V

Load Power (W) 15,000Wp

Solar Power (W) 21,000Wp

Work Time (h) 6-10

Solar Panel:

Model:Polycrystalline

Power:100W*60pcs, total is 6000W

Vmp:17.64V

Imp:5.67A

Products warranty: 5 years

Performance warranty: 90%/10-year, 80%/25-year

AC water pump:

Power:4kw(5.5HP)

Voltage: 3-phase 380V AC, 50Hz
Type: multi-stage centrifugal submersible pump

Motor: water cooling
Outlet: 1.5/2/2.5/3 inch

Head lift:150m~20m

Flow rate:30m3/h/h~5m3/h

Diving depth: ≤70m

Materials:

Impeller: AISI304 stainless steel

Pump body: AISI304 stainless steel

Motor:Cast Iron

Warranty: 18 months

Controller & inverter:

Power:5.5kw

Output voltage: AC, 3-phase 380V,50Hz

MPPT voltage: 450-600V

Function:transfer DC to AC

Warranty: 2 years

Protection:

Over-current/Over-voltage/Over-speed/Over-temperature

Reverse polarity

Dry water

Phase failure

Advantages: High MPPT efficiency, hybrid solar & diesel energy input, soft start/stop

Ground mounting system:

Type: Fixed-type

Foundation: concrete pouring

Material: Q235 industrial steel, Zinc-plated

Warranty: 2 years

Accessories: Combiner box, PV cables, pump cables, water level sensor, pipeline, flange connector and so on.

Applications:

Ecological irrigation/solar drought control, living water supply

Agriculture irrigation/solar desert control

Solar seawater desalination system

Solar city water landscape/pasture irrigation

Optional pump, model number	Rated head	Rated flow	Max. head/min. flow	Min head/Max fax flow	Pump's outlet	Average daily water supply
SK17-25	181m	17m³/h	246m/8m³/h	118m/22m³/h	2.5"	102m³@5.5kWh/m²/day
SK17-26	189m	17m³/h	256m/8m³/h	122m/22m³/h	2.5"	102m³@5.5kWh/m²/day
SK30-16	118m	30m³/h	168m/12m³/h	85m/36m³/h	3"	180m³@5.5kWh/m²/day
SK30-17	125m	30m³/h	179m/12m³/h	90m/36m³/h	3"	180m³@5.5kWh/m²/day
SK42-9	80m	42m³/h	110m/20m³/h	40m/60m³/h	3"	252m³@5.5kWh/m²/day
SK42-10	89m	42m³/h	122m/20m³/h	45m/60m³/h	3"	252m³@5.5kWh/m²/day
SK60-8	61m	60m³/h	96m/30m³/h	35m/75m³/h	4"	360m³@5.5kWh/m²/day
SK60-9-2	64m	60m³/h	102m/30m³/h	36m/75m³/h	4"	360m³@5.5kWh/m²/day
SK75-4	52m	75m³/h	66.5m/50m³/h	40m/90m³/h	5"	450m³@5.5kWh/m²/day
SK120-2-2	27.5m	120m³/h	32m/80m³/h	24.5m/140m³/h	6"	720m³@5.5kWh/m²/day
