Help CenterAC Solar Submersible Pump With Big Flow Rate
Related Products
-
Africa's Largest Solar Pump in Arganeraie Biosphere ReserveUS$ 74,000 - 78,000MOQ: 1 Set -
Solar Water Pumping Continues to Grow in ParaguayUS$ 3,000 - 4,000MOQ: 1 Set
-
Solar Pumping Station in EthiopiaUS$ 3,000 - 4,000MOQ: 1 Set
-
Morocco & North Africa (PV Water Pump Systems)US$ 74,000 - 80,000MOQ: 1 Set
-
Solar Water Pump in Sudan Serves the Environment Development and Agricultural SectorsUS$ 8,000 - 10,000MOQ: 1 Set
- Features:
- Power: 1.1kW
- Voltage: 3-phase 380V AC, 50Hz
- Type: multi-stage centrifugal submersible pump
- Series: water cooling and reinforced motor suitable for solar power
- Max. flow: 36m3/hour
- Max. head: 134m
- Outlet: 1.25/1.5/2/2.5/3 inches
- NEMA standard: 96mm
- Diving depth: ≤50m
- Materials:
- Water outlet: 304 stainless steel
- Impeller: 304 stainless steel
- Pump body: 304 stainless steel
- Motor casing: 304 stainless steel
- Motor shaft: 304 stainless steel
- Screw: 304 stainless steel
- Upper guide bearing, thrust bearing base: cast iron, can be updated to be stainless steel with extra cost if needed
- Water quality: sand content (weight ratio) in water should not exceed 0.01%, chlorine content should not be over 400mg/L
- Max average daily water supply: 200m³ at 5.5KWh/m²/day
- Warranty: 18 months, extend to 2-year warranty optional with extra cost
- Advantages: up to 15yrs lifespan, working is reliable and stable
- Controller and inverter:
- Power: 1.5kW
- Input voltage range: 330-710V
- Output voltage: AC, 3-phase 380V
- MPPT range: 450-600V
- Max MPPT efficiency: ≥97%, soft start/stop
- Warranty: 2-year, extended to 3-year warranty optional with extra cost
- Protection:
- Over-current, over-voltage, over-speed, over-temperature
- Reverse polarity
- Dry water/phase failure protection
- Advantages: high MPPT efficiency function, GMS remote control, auxiliary diesel power/3 phase AC electricity hybrid power transfer-switch controller, water flow control regulator, soft start/stop
- Solar panel reference:
- Power: mono/poly, totally about 1500W
- Positive tolerance: +0/5W
- Products warranty: 5 years
- Performance warranty: 90%/10 years, 80%/25 years
- Mounting system:
- Type: fixed mode/pillar manual tracking/slanting uniaxial tracking
- Foundation: concrete pouring
- Installation type: 6 pieces/array and vertical
- Warranty: 5 years
- Material: hot-dip galvanized
- Combiner box: N/A
- Accessories: PV cables, water pump cables, water level detective sensor, cable sleeves, pipeline, flange, riser pipe
- The quantity of accessory materials are based on actual design
- Applications:
- Ecological irrigation
- Solar drought control, living water supply
- Agriculture irrigation
- Solar desert control
- Solar seawater desalination system
- Solar city water landscape
- Pasture irrigation
“TOP OF WELL” also means “PITLESS ADAPTOR LEVEL”
“Service Inlet” also means “STORAGE TANK INLET”
Standing or Static Water Level – distance from top of well to natural water level when pump is not operating.
Drawdown distance – distance water level drops while pump is operating.
Drawdown level – standing water level plus drawdown.
Submergence – distance submersible pump intake screen is installed below drawdown level.
Elevation – vertical distance between top of well to pump inlet screen.
Pump Setting – distance from top of well to pump inlet screen.
Pumping Level – distance from drawdown level to service inlet.
Service Pressure – pressure (in PSI) at service inlet.
Friction Loss – loss of pressure due to friction of water flowing through pipe and fittings.
Total Discharge Head – discharge head (in feet) delivered when pump is operating at desired capacity.
Horizontal Pipe Run – horizontal distance between service inlet and well.
NOTE: PSI can be converted to equivalent feet of head by multiplying by 2.31.
MAXIMUM TOTAL HEAD is the maximum pressure that can be developed by the pump. This is always given in feet of head rather than in pounds. The pump selected must have a maximum total head greater than the sum of the PUMPING LEVEL and the TOTAL DISCHARGE HEAD.
When figuring PUMPING LEVEL the following conditions must be considered:
STANDING WATER LEVEL is the distance from the top of well to the top of the water when the pump is not operating.
DRAWDOWN is the distance the water level drops below the standing water level while pump is operating.
SUBMERGENCE is the distance the injector, submersible pump, or foot valve is installed below the pumping level.
Pump selection is critical for proper well operation
The answer to four basic questions will help select the proper pump.
1. WHAT IS THE SIZE OF THE WELL? The inside diameter of the well must be known so that the proper size pump, injector, cylinder or drop pipe and foot valve can be determined.
2. WHAT IS THE PUMPING LEVEL? The vertical distance in feet from the pump to the water level while the pump is operating. If the pump is installed away from the well and is on higher ground, this elevation must also be included. Most wells draw down while being pumped so this must not be confused with the standing water level.
3. WHAT SHOULD BE THE AVERAGE DISCHARGE PRESSURE? Usual average discharge pressure is 40 lbs. – halfway between the 30 lbs. To 50 lb. switch settings of most water systems. When the tank is installed away from the pump at a higher level, or when the house or yard fixtures are above the pump and tank, a greater pressure is needed and a larger pump must be used.
4. WHAT CAPACITY IS REQUIRED? The discharge capacity of the pump in gallons per hour that is needed for satisfactory service. The pump should have enough capacity so that it can deliver the total water requirement in 2 hours of continuous operation. See the tables below for some average water use requirements.
AVERAGE WATER REQUIREMENTS FOR GENERAL SERVICE | |
Each person per day, for all purposes |
100 gal. |
Each horse, dry cow or beef animal per day |
12 gal. |
Each milking cow per day |
35 gal. |
Each hog per day |
4 gal. |
Each sheep per day |
2 gal. |
Each 100 chickens per day |
6 gal. |
AVERAGE AMOUNT OF WATER REQUIRED | |
Drinking fountain (continuously flowing) |
50 to 100 gal. per day |
Each shower bath |
Up to 60 gal. |
To fill bathtub |
30 gal. |
To flush toilet |
6 gal. |
To fill lavatory |
2 gal. |
To sprinkle 1/4" of water on each 1000 sq. feet of lawn 160 gal. Dishwasher per load 3 gal. Automatic washer per load Up to 50 gal. Regeneration of domestic water softener 50-100 gal. | |
AVERAGE FLOW RATE REQUIREMENTS BY VARIOUS FIXTURES (GPM equals gallons per minute; GPH equals gallons per hour) | |
Shower |
4 to 6 GPM |
Bathtub |
4 to 8 GPM |
Toilet |
4 to 5 GPM |
Lavatory |
1 to 4 GPM |
Kitchen sink |
3 to 5 GPM |
/2" hose and nozzle 200 GPH |
300 GPH |
Lawn sprinkler | |
Pump Performance Curve
Solar & Diesel Pumping System comparison
Installation and maintenance for the solar water pump
