good quality best selling cheap cnc plasma cutting machine
The gantry cheap CNC plasma cutting machine is specially designed for metal plate cutting, it is characterized of high automation and efficiency, easy operation and longer service time. It is with double-drive system, working size can be customized upon requirement.
features of cheap cnc plasma cutting machine
l Main frame: adopted to thermal aged, avoid disfigure.
l Horizontal straight double-shaft axles guiding rail, equipped Taiwan HSK or Taiwan HIWIN
l 7-grade precision rack
l Servo motor :Brand Japan Panasonic and planetary reductor: Japan SHIMPO or Germany NEUGART.
l Controll system: USA Hypertherm EDGE Pro
l Plasma power (optional),but main is USA Hypertherm.As customer required also can equipped:USA KALIBURN, Germany Kjellberg or some made in China like:Shanghai Jiaoda.
l Automatic Programming and Fastcam: Australia FASTCAM (Professional)
l Plasma torch with Arc volt auto height-regulating device and 360°anti-collision device
l Flame torch: with capacitive auto height-regulating device, Auto ignition device, Solenoid Valve: Italy CEME and flashback arrestor. The whole torch brand: USA G&R.Air tube is Brand Korean YASUNG
technical parameters of cheap cnc plasma cutting machine
No |
item |
specification |
||||||
1 |
Horizontal track space(mm) |
4000 |
4500 |
5000 |
5500 |
6000 |
6500 |
7000 |
2 |
effective cutting width(mm) |
3200 |
3700 |
4200 |
4700 |
5200 |
5700 |
6200 |
3 |
Overall width (mm) |
4800 |
5300 |
5800 |
6300 |
6800 |
7300 |
7800 |
4 |
Cutting mode |
flame only,plasma only,flame and plasma |
||||||
5 |
Driving method |
rack and pinion drive for X and Y axes |
||||||
6 |
Driving mode |
double-side driving |
||||||
7 |
Flame cutting thickness |
6-200mm |
||||||
8 |
Plasma cutting thickness |
0-50mm(according to plasma power source) |
||||||
9 |
Cutting speed |
0-6000mm/min |
||||||
10 |
Empty stroke speed |
0-10000mm/min |
||||||
11 |
Automatic height controller |
capacitive height control for flame cutting arc voltage height control for plasma cutting |
||||||
12 |
Cutting gas |
acetylene,propane(optional) |
||||||
13 |
Plasma gas |
pressed air,oxygen,N2 |
||||||
14 |
Marking tool |
yes(Optional) |
||||||
15 |
Nesting software (optional) |
Integnps,Fast cam |
||||||
l Professional engineering and technical personnel. We will provide you with reasonable and valuable Suggestions and solutions according to your requirements, the engineering feasibility and economic benefit etc .
l Provide knowledge of equipment operation and maintenance,Allows you to accurately grasp the characteristics of the machine
l one year warranty, life-long maintenance services through email or telphone .Please feel free to use.
l Supply all kinds of accessories and replacement.
With constant efforts of all staffs, our products have been sold well in domestic and exported to many countries inthe world, including Australia,Indonesia,India,Burma,Iran,Spain,Brasil,Peru,Russia,Azerbaijan,KZ,UZ,Sri Lanka etc.
HUAFEI would like to your loyal friend, welcome to visit our factory.
If you have any questions, please feel free to contact us, we are always at your service!
Skype:huafei0531
Tel:0086-15053136913
