TIG MIG Cylinder docking longitudinal /straight seam welding machine
Cylinder docking straight seam welding machine is a gerneral automatic welding machine which can complete the welding of thin cylinder,cone tank, plate and square box with one open mouth with thickness 0.5-5mm characterized good-quality, high efficiency and distortionless.Cylinder docking straight seam welding machine can be used to weld carbon steel, low alloy steel,stainlesss steel , aluminum and its alloy and so on. Argon arc welding (wire filling or not filling) gas metal arc welding ((CO2/MIG/MAG), plasma welding are optional to complete one set of longitudinal seam welding system.
Cylinder docking straight seam welding machine is widely used to aerospace vehicles,thin-walled pressure vessel,auto spares parts,household appliance ,medical devices ,architectural ornament ,food machinery and other industries which need longitudinal seam welding.
model |
ZF-500 |
ZF-1000 |
ZF-1500 |
ZF-2000 |
ZF-2500 |
ZF-3000 |
|
Welding length |
525 mm |
1125 mm |
1650 mm |
2025 mm |
2550 mm |
3075 mm |
|
|
Min. diameter |
φ75 mm |
φ115 mm |
φ150 mm |
φ180 mm |
φ200 mm |
φ270 mm |
|
|
Max diameter |
φ850 mm |
φ730 mm |
φ730 mm |
φ850 mm |
φ850 mm |
φ850 mm |
|
Welding thickness |
0.2-6 mm |
0.4-6 mm |
0.8-8 mm |
||||
Welding speed |
150-1500 mm/min |
||||||
Speed control |
Stepless speed control |
||||||
Transmission mode |
Guide rail+gear and rack |
||||||
Slide precision |
±0.15 mm |
±0.2 mm |
|||||
Clamping mode |
Key type Pneumatic clamping |
||||||
Optional |
1.analog control;2.torch screen+PLC control; |
||||||
3.American welding source;4.china welding source;5.others | |||||||
l Professional engineering and technical personnel. We will provide you with reasonable and valuable Suggestions and solutions according to your requirements, the engineering feasibility and economic benefit etc .
l Provide knowledge of equipment operation and maintenance,Allows you to accurately grasp the characteristics of the machine
l one year warranty, life-long maintenance services through email or telphone .Please feel free to use.
l Supply all kinds of accessories and replacement.
With constant efforts of all staffs, our products have been sold well in domestic and exported to many countries inthe world, including Australia,Indonesia,India,Burma,Iran,Spain,Brasil,Peru,Russia,Azerbaijan,KZ,UZ,Sri Lanka etc.
HUAFEI would like to your loyal friend, welcome to visit our factory.
If you have any questions, please feel free to contact us, we are always at your service!
Skype:huafei0531
Tel:0086-15053136913
