HFSCL-2*1600 the uncoiler lever shear
General introduction of slitting and cut to length combined line
The shearing and slitting production line is complex multifunctional composite shear production line, both slitting rewinding, but also cross-cut stacking; you can also receive curling cross cut stacking.
Shear vertical and horizontal lines on the material production line mainly consists of loading car, uncoiler, leveling machine, slitting machine, scrap side winder, tension agencies, rolling machines, unloading equipment, shearing machines, stacks devices.
The line combines cross cutting line and slitting line applied in the enterprises which using various kind of sheets.
Technical Data .Parameter
|
Model/ Parameter |
Cutting thickness(mm) |
Cutting width(mm) |
No. of slitting cutting(mm) |
Precision of Shearing cutting (mm) |
Speed of shearing cutting(m/min) |
Speed of slitting cutting(m/min) |
Roller weight(ton) |
HFSCL-2*1300 |
0.35-2 |
500-1300 |
6-15 |
±0.3 |
40 |
50 |
15 |
HFSCL-2*1600 |
0.35-2 |
500-1600 |
6-15 |
±0.3 |
40 |
50 |
15 |
HFSCL-2*1850 |
0.35-2 |
900-1850 |
6-15 |
±0.3 |
40 |
50 |
20 |
HFSCL-3*1600 |
0.5-3 |
500-1600 |
6-15 |
±0.3 |
40 |
50 |
15 |
HFSCL-3*1850 |
0.5-3 |
900-1850 |
6-15 |
±0.3 |
40 |
50 |
20 |
HFSCL-4*1600 |
0.5-4 |
900-1600 |
5-12 |
±0.3 |
25 |
40 |
20 |
HFSCL-6*1600 |
1-6 |
900-1600 |
4-10 |
±0.5 |
20 |
35 |
20 |
The dimension of the whole line can be made according to customer’s requirement
Electric source:
Voltage: 380V, 3 phase, AC ±5%
Frequency: 50Hz±1%
Since establishment, extensive experience has been accumulated and advanced QMS and professional after-sales service been built. Our HUAFEI brand
machineries are produced strictly under the requirement of ISO9001 and professional after-sales service well provided by our experienced and devoted after-sales staffs.
Warranty: one year warranty from the date of delivery (excluding quick-wear parts), free repairing service for non-artificial damages within guarantee period, also free service can be provided only with spare parts charged after warranty period expires.
Training: Technicians will be sent for installing and commissioning, after testing, free training will be provided till operation mastered and machine running normal.
Maintenance: Once faults occur out of no particular reason, technicians will be sent for repairing within 24 hours (48 hours for out-of-province) after receiving notice.
Parts: spare parts are available all the time for customers
Documents: relevant documents, operation instruction, parts description etc, will be provided after contract comes into effect.
Technical support: technical support and maintenance will be provided by professional technicians during machine usage
