TCK-42L/42LS Emco Cnc Lathe Machine Job Work
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TCK-40L/40HL Cnc Lathe Jobs Machine Price ListNegotiableMOQ: 1 Set -
T5 Cnc Vertical Turret Milling Machine for MetalNegotiableMOQ: 1 Set
-
T7 Cnc Combination Lathe Milling Machine Price ListNegotiableMOQ: 1 Set
-
VMC-650 China Low Cost Mini CNC Milling MachineNegotiableMOQ: 1 Set
-
TY-500 Chinese Cnc Vertical Machining Center for SaleNegotiableMOQ: 1 Set
Condition
New
Type
Horizontal
CNC or Not
CNC
Automatic Grade
Automatic
Place of Origin
China
Brand Name
HHT
Model Number
TCK-42L,42HS
Certification
ISO/CE
After-sales Service Provided
Engineers available to service machinery overseas
TCK-42L/42LS emco cnc lathe machine job work
Feature:
- Maximum spindle speed:5000rmp
- Spindle hole diameter:56mm
- Maximum processing diameter:360mm
- X/Z axis rapid traverse:24m/min
TCK-42L use 30° inclined type layout,integrated bed and base with cast iron structure,enhance the integral rigidity and stability of the machine tool,improve the quality of workpiece,has higher performance price ratio.
Specifications:
| Item Model | Name | Unit | TCK-42L | TCK-42LS |
| Processing range parameters | The maximun rotating diameter of bed | mm | Φ360 | Φ420 |
| Maximum processing diameter | mm | Φ360 | Φ420 |
|
| Swing over carriage | mm | Φ126 | Φ128 |
|
| Maximum processing length | mm | 290 | 330 | |
| Bar diameter | mm | Φ45 | Φ45 |
|
|
spindle motor hydrocylinder Chuck |
Spindle nose | / | A2-5 | A2-5 |
| Spindle hole diameter | mm | Φ56 |
Φ56 |
|
| Maximum speed of spindle | rpm | 5000 | 5000 | |
| Spindle motor power | kw | 5.5/5.7kw | 5.5/5.7kw |
|
| Hydraulic Cylinder/Chuck | / | 6° | 6° |
|
| X/Z axis feed parameter | X motor power | rpm | 1.3 | 1.3 |
| Z motor power | kw | 1.3 | 1.3 | |
| X travel | mm | 400 | 480 | |
| Z travel | mm | 300 | 350 | |
| X/Z axis rapid traverse | m/min | 24 | 30/24 | |
| positioning accuracy | mm | ±0.005 | ±0.005 | |
| repeat positioning accuracy | mm | ±0.003 | ±0.003 |
|
| Slide rail type | / | line rail 30mm | line rail 35mm |
|
| parameter | Tool position | pcs | gang | gang |
| The quartet cutter holder specification | mm | 20 | 20 |
|
| Circular cutter holder specification | mm | Φ20 | Φ20 |
|
| The adjacent tool change time | sec | 0.25 | 0.25 |
|
| Outline dimensions | Length X width | mm | 2500*1850*1400 | 2550*1880*1500 |
| Weight | kg | 2600 | 2680 |
*We reserve the rights on the designing,colors,specification and termination of use of our products.Changes to these factors will not be notified.
Payment Terms:
- 30% Deposit by TT before production and 70% payment by TT before shipment.
- 30% Deposit by TT before production and 70% L/C at sight before shipment
- 100% L/C at sight
