T7 Cnc Combination Lathe Milling Machine Price List

T7 Cnc Combination Lathe Milling Machine Price List thumbnail-1
T7 Cnc Combination Lathe Milling Machine Price List photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
HHT
Contact Supplier Request Quote Chat Now
Huaian Haoyang Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Brand Name HHT
Model Number T7
CNC or Not CNC
Dimension(L*W*H) 2300*2100*2400
Weight 3800kg
Certification ISO/CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

 T7 cnc combination lathe milling machine price list





High speed feed system

  • Rapid,simple,reliable and long life of cutter switching device,tool exchange provide stable and reliable.Unique tool switching device design,the advanced CAM drive-echanism,cutter selection ability,at any position can be controlled by PLC software quickly.
  • CAM driven knife library can ensure accuracy of otation,when using heavy tools can smo oth running.
The structure design of high rigidity,high precision
  • Main structure USES the high strength cast iron casting,the organization is stable and permanent to ensure quality.Casting through finite element analysis,the computer calculation and analysis,the reasonable structure strength and the collocation of stiffening rib,provide high rigidity of the machine.

Specification:
 Item Model Unit  T7
working table size mm 400*800
X/Y/travel mm 700/400/300
stance between spindle end and table mm 155-455
Distance between spindle center and column guide way mm 450
Maximum weight of working table kg 250
X/Y/Z axis rapid feed m/min 48
Clamp arm type magazine tool pcs BT30-16T
spindle speed rmp 12000
spindle taper mm BT-30/100
control system / Mitsubishi-M70VB/FANUC01-MATE ED
torque force of spindle motor kw 5.5
torque force of X.Y.Z motor nm 12/12/20
machine size mm 2300*2100*2400
machine weight kg 3800

Standard accessories:
  1. All closed shield
  2. The electrical box heat exchanger
  3. The spindle direct drive
  4. Cutting cooling unit
  5. Cutting blower
  6. Main shaft blowing
  7. Rigid tapping
  8. Stored procedures
  9. Automatic lubrication system
  10. Level of bolt and block
  11. 16 PCS clamp arm type knife library
  12. DNC computer transmission line
  13. Three axis screw device
  14. Three axis telescopic cover
  15. Three color warning light
  16. Operation and maintenance manuals
  17. Explosion-proof working lamp
  18. The case the handwheel
  19. The toolkit
The choose and buy accessories:
  1. Five axis four turn table
  2. The forth turn rotaryworktable
  3. Automatic blade lengthmeasuring system
  4. Spindle center out of the water
  5. Voltage regulator
  6. The chip removal machine

Payment Terms

  1. 30% Deposit by TT before production and 70% payment by TT before shipment
  2. 30% deposit by TT before production and 70% L/C at sight before shipment
  3. 100% L/C at sight
