Specifications
Large Scale Floor Type Milling Machine
1.ISO/CE
2.Fanuc/Siemens
3.Large Scale Floor Type Milling Machine
|
Cnc Floor type boring milling machine |
|||||
Specifications |
CFBR130 |
CFBR160 |
CFBR200 |
CFBR230 |
CFBR260 |
|
Spindle diameter |
130mm |
160mm |
200mm |
230mm |
260mm |
|
Diameter of milling spindle |
221.44mm |
240mm |
300mm |
380mm |
400mm |
|
Ram size |
450×500mm |
450×500mm |
500×580mm |
600×700mm |
600×725mm |
|
Spindle speed |
10-1500r/min |
10-1200r/min(or 5-1500) |
5-1350r/min |
5-1000r/min |
5-900r/min |
|
Spindle taper |
ISO50 7:24 |
ISO50 7:24 |
ISO60 7:24 |
ISO60 7:24 |
ISO 60 7:24 |
|
Power of Spindle motor |
30/41KW |
37/51KW(or 51/71) |
71/114kW |
100/140kW |
130/150kW |
|
Motor total power |
100kW |
120kW |
160kW |
180kW |
220kW |
|
Spindle torque |
3500Nm |
4000Nm |
11500Nm |
15000Nm |
28000Nm |
|
Torque of milling force |
4000Nm |
5000Nm |
13500Nm |
15500Nm |
30000Nm |
|
Spindle resisting force |
35000N |
40000N |
60000N |
65000N |
70000N |
|
Shank |
JT50# |
JT50# |
JT60# |
JT60# |
JT60# |
|
Pull stud |
LDA-50 |
LDA-50D |
LDA-60 |
LDA-60 |
LDA-60 |
|
Cross travel of column X |
4000mm (optional) |
6000mm(or longer) |
10000mm(or longer) |
12000mm(or longer) |
12000mm(or longer) |
|
Vertical travel of spindle head Y |
2000mm (or 2500, 3000) |
3000mm(or 4000) |
4000mm (or longer) |
4000mm(or longer) |
5000mm(or longer) |
|
Ram travel |
900mm |
1000mm |
1200mm |
1300mm |
1800mm |
|
Axial travel of spindle W |
800mm |
900mm |
1200mm |
1300mm |
1600mm |
|
|
Rapid traverse X Y ZW |
10000 /6000 6000mm/min |
10000 /6000 6000mm/min |
8000mm/min 6000mm/min |
8000mm/min 6000mm/min |
8000mm/min 6000mm/min |
|
|
Feedrate X Y ZW |
1-6000mm/min 1-4000mm/min |
1-6000mm/min 1-4000mm/min |
1-4000mm/min |
1-4000mm/min |
1-4000mm/min |
|
|
Positioning accuracy X, Y Z,W |
±0.015/1000mm ±0.02mm |
±0.015/1000mm 0.025mm |
±0.015/1000mm 0.02mm |
±0.015/1000mm 0.02mm |
±0.02/1000mm 0.03mm |
|
|
Repeatability accuracy X, Y Z,W |
±0.01mm ±0.015 |
±0.01mm ±0.02mm |
±0.01mm |
±0.01mm |
±0.015mm |
|
CNC system |
SIMESNS OR FAMUC |
SIEMENS OR FANUC |
SIEMENS OR FANUC |
SIEMENS OR FANUC |
SIEMENS OR FANUC |
|
Weight |
68000kg |
126000kg (145000) |
153000kg |
166000kg |
228000kg |
|
