3D laser marking Larger Scale Laser Subsurface Engraving Machine
Technique Specification:
Model LD-EG-603C
Price CIF Chennai 70LD-EG-602B 000.00USD
Laser medium YAG
Laser wavelength 532nm (green laser)
Max. pulse energy 1mJ(0.5mJ)
Max. laser power 2W
Frequency 3000 Hz
Pump source Diode/USA
Pump source lifetime
useful life
20000hours
Original place of
Laser medium
German
F-theta lens(mm) German F:160
Laser heads 1
Engraving speed
(dots/min)
140,000-180,000/min
Working way 1 scanner
Drive System servo motor
Engraving range(mm) 3000*1500*3-120
F-theta lens 160
Engraving time
558 crystal(200,000points)
About 2 min.
321keychain(70,000ponits)
About 0.6min.
Repeated location accuracy 5μm
Continuous working time >12hours
Power consumption 1.5KW
Cooling way Water Cooling
Power supply 220V or 110V±10% 50Hz or 60Hz
Warranty 2 year
Machine dimension (mm)
of Whole machine(mm)
2100mm×3100mm×1200mm
Total Weight (kg) 450 kg for the machine, 30 kg for the water cooling
Computer CPU:P4 2.8G, Memory 1G,Harddisk 80G,17”LCD
Software Laser photo, Laser image, Laser control (The software is developed by lead
laser)
Circumstance temperature 15-30℃
Relative humidity less 75%
Training time 3 days
Laser class laser 4
Laser class system 1
Remark
This quotation included 1 set engraving system, operating computer for
machine, operating software installed in the computer, more than 2000pcs 2D/3D images data installed, free training, whole life maintenance and
technological support, manual and spare parts .
Training:
a. 3--4 days free training for the whole system in Seller’s company
b. If customer needs our technician give the training abroad, the Customer need
charge for the transportation and accommodation fees of engineer;
Including: how to set up the equipment;
how to debug the light route;
Packing and Contents:
Equipment will be packed into two standard wooden cartons, suitable for vessel or airtransport, and marked the universal label, shipping marks etc.
