Help CenterH32 GNSS RTK GPS
US$ 1 - 10
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Gps Receiver
Use:
Other, Surveying and Mapping
Screen Size:
Other, 3.7inch controller
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Geodetic Surveying Distance Measuring Total StationUS$ 0.1 - 0.2MOQ: 1 Set -
HI-TARGET Dual Frequency RTK GPSUS$ 0.1 - 0.2MOQ: 1 Set
-
New Condition Geodetic Surveying RTK GPSUS$ 0.1 - 0.2MOQ: 1 Set
-
Land Surveying V90 Plus RTK GPS With GNSS SystemUS$ 0.1 - 0.2MOQ: 1 Set
-
HI-TARGET V100 Network RTK GPSUS$ 0.1 - 0.2MOQ: 1 Set
Type
Gps Receiver
Use
Other, Surveying and Mapping
Screen Size
Other, 3.7inch controller
Function
Bluetooth-enabled, Mp3/Mp4, Radio Tuner, Touch Screen
Place of Origin
Chongqing, China
Brand Name
Hi-Target H32 RTK GPS
Model Number
H32 RTK GPS
Warranty
12 Months
High Pressional H32 RTK GPS Made in China
Originated from HI-TARGET’s sophisticated GNSS technology, the H32 RTK GPS is a very competitive GNSS RTK system on the current market with its rugged design and affordable price.
The H32’s housing is made of General Electric Xenoy 5220U polymer resin to handle severe and harsh filed conditions. With its unique internal design, it can perfectly avoid or lessen obstruction and multipath effect to ensure superior positioning capability.
The H32 RTK GPS’s front control panel with super bright OLED display screen (Resolution 128x64) makes the work more intuitive. No matter it is in the dark or strong sunshine, the screen is comfortably readable to eyes.
Technical Parameter of the H32 RTK GPS:
| Measurement | • 120 Channels |
• Proven NovAtel GNSS technology | |
• Multipath mitigating technology | |
• Auxiliary strobe signals, including a configurable output for time synchronization and mark inputs | |
| Satellite signals tracked simultaneously | |
GPS: L1, L2, L2C | |
GLONASS: L1, L2 | |
Galileo: E1 | |
GIOVE-A/GIOVE-B (test) | |
BDS/Compass | |
SBAS | |
QZSS | |
| Positioning Perfromance | Static and Fast Static GNSS surveying |
Horizontal: 2.5mm+0.5ppm RMS | |
Vertical: 5mm+0.5ppm RMS | |
Post Processing Kinematic | |
*(PPK / Stop & Go) GNSS surveying | |
Horizontal: 1cm+1ppm RMS | |
Vertical: 2.5cm+1ppm RMS | |
Initialization time: typically 10 minutes for base while 5 minutes for rover | |
Initialization reliability: typically > 99.9% | |
*Real-time Kinematic (RTK) surveying | |
Horizontal: 10mm+1ppm RMS | |
Vertical: 20mm+1ppm RMS | |
Initialization time: typically < 10 seconds | |
Initialization reliability: typically > 99.9% | |
*Code Differential GNSS positioning | |
Horizontal: 25cm+1ppm RMS | |
Vertical: 50cm+1ppm RMS | |
SBAS: 0.60m Horizontal | |
Hardware |
Physical |
Dimensions (w x H): 16.5 cm x 10.5 cm (6.50 in x 4.13 in) | |
Weight: 1.75kg (3.86lb) with internal battery, internal radio, standard UHF antenna | |
Operating temperature: -45℃to +65℃ (-49℉ to +149℉) | |
Storage temperature: -55℃ to +85℃ (-67℉ to +185℉) | |
Humidity: 100%, considering | |
Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft). | |
Shock and Vibration: Designed to survive a 2m (6.56ft) natural fall onto concrete. | |
Display: 128×64 resolution, 1.54 inch OLED screen | |
Electrical | |
Power 6V to 28V DC external power input | |
Power consumption 2.5W | |
Automatic Switching between internal power and external power | |
Rechargeable, removable 7.4V, 4400mAh Lithium-Ion battery in internal battery compartment | |
Internal battery life | |
Static 13 - 15 hours | |
RTK Rover (UHF/GPRS) 10 - 12 hours | |
RTK Base 8 - 10 hours | |
I/O interface | |
1 x Bluetooth | |
1 x standard USB2.0 port | |
2 x RS232 serial port | |
2 x DC power input (8-pin & 5-pin) | |
Communication and Data Storage |
GPRS/GSM |
Fully integrated, fully sealed internal GPRS/GSM | |
Network RTK (via CORS) range 20-50km | |
HI-TARGET internal UHF radio (standard) | |
Frequency: 460 MHz with 116 channels | |
Transmitting Power: 0.1W, 1W, 2W adjustable | |
Transmitting Speed: Up to 19.2Kbps | |
Working range: 3~5Km typical, 8~10km optimal | |
HI-TARGET External UHF radio (standard) | |
Frequency: 460 MHz with 116 channels | |
Transmitting Power: 5W, 10W, 20W, 30W adjustable | |
Transmitting Speed: Up to 19.2Kbps | |
Working Range: 8~10Km typical, 15~20km optimal | |
Support other external communication device | |
For example, external GSM modem. | |
Data storage | |
64MB internal memory | |
Data formats | |
(1Hz positioning output, up to 50 Hz - depends on installed option) | |
CMR: CMR+, CMR input and output | |
RTCM: RTCM 2.1, 2.3, 3.0, 3.1 input and output | |
RTCA: RTCA | |
Navigationoutputs: NMEA-0183, NovAtel ASCII and Binary logs |
*The Main Features of The Hi Target RTK GPS:
Multi Constellation Tracking
120 channels. The H32 is fully compatible with GNSS constellations to track GLONASS, GALILEO, SBAS as well as GPS.
All-in-one Transceiver UHF Radio
The transceiver UHF radio enables the H32’s working mode to be switchable between base and rover in the same receiver. The H32 provides excellent performance in UHF RTK operation with its built-in transceiver UHF radio, which has adjustable transmitting power from o.1 Watt to 2 Watts.
Seamlessly Operation in CORS System
With internal GPRS modem, the H32 works perfectly with corrections from CORS networks in any version of CMR, RTCM without needing to interpret the message but reading seamlessly.
Powerful Battery
Powered by 4400mAh Li-Ion battery.
Static working time 13 - 15 hours
RTK Rover (UHF/GPRS) working time 10 - 12 hours
RTK Base working time 8 - 10 hours
Rugged design, IP67
The special latching technology on flexible flat cables ensures trouble-free operation under impact or vibration. The H32 withstands 2 meters natural fall onto concrete.
Field Controller and Software
There are optional field controllers and software in the H32 package. The controllers with OS Microsoft Windows Mobile 6.5 are fully compatible with the third party software such as Carlson SurvCE, MicroSurvey FieldGenius, Digiterra Explorer, Esri ArcPad etc. besides standard field&GIS software made by HI-TARGET. HI-TARGET controller with WiFi, Bluetooth, and GPRS/3G is completely wireless to connect to any device, collect data and connect to server simultaneously and seamlessly.
Post-processing Software
HI-TARGET Geomatics Office (HGO) software provides total GNSS solution with a complete suite of programs to support HI-TARGET GNSS receivers. Standard Rinex data and HI-TARGET raw data can be processed flexibly and easily.
*Why Choose US?
