Qmini M
(RTK controller and RTK and GIS data collector )
Qmini MP ultra-lightweight tray design, operate friendly with a strength approval. It can work as RTK controller by Bluetooth wireless. It is fully compatible with third-party software with OS Microsoft Windows Mobile 6.5 operating system. Built-in professional GPS module achieves the perfect combination of RTK and GIS data collection.
System Features:
Rugged design
Microsoft Windows Mobile 6.5
806MHz high-speed CPU
Embedded high sensitivity GPS+GLONASS receiver
3.7 inch QVGA TFT, sunlight - readable color touch screen
5 Megapixel auto-focus camera with LED
Field swappable long life Li-Ion battery
Technical parameters:
SYSTEM CONFIGURATION:
Operating system: Windows Mobile 6.5
Processor: 806 MHz
RAM: 256 MB RAM
Flash memory: 8 GB
Display: 3.7 inch LED, 640×480 resolution
GPS FEATURES
GPS L1&BDS B1
Built-in high sensitivity anti-interference GPS antenna
Update rate: 1 fix/s (user configurable)
Update rate: 1 Hz (configurable w/ future FW 2 Hz Max)
Time to first fix (TTFF): 35 seconds (typical)
POSITION ACCURACY
Single Point Positioning: 5 m
APPLICATION FUNCTIONS
5 million pixel camera with LED
Built-in speaker
COMMUNICATION INTERFACE
Bluetooth
Mini USB
WIFI:802.11b/g
MicroSD card slot, support up to 32 GB
Built-in 3G module
POWER SUPPLY
3.7V, 3100 mAh lithium battery, up to 8 hours continuous work, online charging
PHYSICAL PROPERTIES
10 keys, with the four arrow keys
Size: 152 mm x 82 mm x 32 mm
Weight: 315 g (with battery)
Operating temperature: -20℃~+70℃
Storage temperature: -30℃~+80℃
Dustproof / waterproof: IP65
Anti-shock: 1.5 m free fall
Applications:
With Windows Mobile 6.5 you may upload necessary utilities or software on your Qmini M ,to suit your next job .You can collect GIS/GPS points and maps via the GIS application of your choice , either a third-party software such as ESRI ,ARCPAD or the proprietary Hi-Target application.
More Information:
Specification subject to change without notice. Battery performance will vary based on software applications, wireless settings, power management settings, LCD brightness, customized modules and environmental conditions. As with all batteries, maximum capacity decreases with time and use and may eventually need to be replaced by a Hi-Target service provider. Battery life and charge cycles vary by use and settings. Battery life may be reduced in subzero applications.
