XY-5T Truck mounted water well drilling rig
best choice for water well
2015 new product truck mounted water drilling
Truck mounted water drilling machine XY-5T is mounted on a high-performance 6-drive off-road chassis and contains the drill rig, drill mast, mud pump and the hoist is a new type truck mounted drilling machine for diamond drilling, it can drill both straight holes and inclined holes.
Specification: | |
Drilling Depth |
1200m |
Spindle rotating speed |
85~1232r/min |
Spindle stroke |
500mm |
Max. hoist capacity |
135KN |
Engine Power |
Cummins 6BT5.9/132KW |
Hoist |
SJ3000 |
Mud Pump |
BW250 |
Mast height |
11m |
Max. load capacity |
160KN |
Max. swing angle of Mast |
90°--60° |
Dimension |
9400*2446*11100(Work condition) 9400*2446*4000(Travel condition) |
1.Core Drilling Machine 2.Water Well Drilling machine 3.Anchoring Drilling Machine
4.Down-the-hole Drilling Machine 5.Underground Drilling Machine 6.Horizontal Directional Drilling Rig
