High Efficiency Soil Sampling Core Drilling Rig
This core drilling rig is widely used in tunnel drilling, geological prospecting, also suitable for geological drilling for hydroelectric power station building, highway, roadway, harbor and drilling pile grouting hole.
This core drilling rig has such features as small body, light weight; especially available for construction of hydroelectric power station.
It can get two series of speeds by means of substitution of one pair of helical gears for other one.
Depth: 150-300m
Spindle speed: Forward: 81/164/298/334/587/1190 (r/min)
Reverse: 98/199 (r/min)
Maximum torque: 1110Nm
Angle range: 0~90°
Spindle stroke: 500mm
Power unit: Electric YD180L-4/8 17/11KW, Diesel 295D 13.2KW
Overall dimensions: 1720 * 800 * 1300mm 650kg
Model |
XY-2 |
XY-2B |
XY-44C |
GX-50 |
Depth (m) |
100-530 |
100-530 |
750-1400 |
20-100 |
Diameter (mm) |
75-200 |
96-200 |
93-200 |
75-150 |
Power unit |
Electric/22kw |
Electric/22kw |
Electric/37kw |
Electric/7.5kw |
|
Diesel/20kw |
Diesel/20kw |
Diesel/50kw |
Diesel/8.8kw |
Dimension (mm) |
2015*900*1690 |
2220*900*1880 |
3038*1100*1938 |
1360*620*1080 |
Weight (kg) |
950 |
1200 |
350 |
360 |
Any question you want to be answered, please feel free to contact:
