Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Mini Drilling Rig Water From China Construction Equipments GQ-15 Construction Drilling Rig
Mini Drilling Rig Water From China Construction Equipments GQ-15 Construction Drilling Rig
US$ 32,000 - 32,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, construction drilling
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Engineering Drill Rigs GQ-20 for ConstructionNegotiableMOQ: 1 Set -
Drilling Rig GQ-60, Drill, Rotary DrillNegotiableMOQ: 1 Set
-
Spindle Drilling Rig GQ-20 for Ground Investigation DesignNegotiableMOQ: 1 Set
-
Borewell Drilling Rig GXY-100 Hydraulic Air Water Drilling RigUS$ 9,999 - 9,999MOQ: 1 Set
-
ZLJ-3300 Diamond Core Borewell Drilling MachineUS$ 9,998 - 9,998MOQ: 1 Set
Condition
New
Type
Other, construction drilling
Power Type
Diesel
Place of Origin
Chongqing, China
Brand Name
Gold
Model Number
GQ-15
Usage
Other, construction drilling
Voltage
380V
Power(W)
19.85 kw
Dimension(L*W*H)
3030*1250*1935mm
Certification
CE
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
GQ-15 used for construction drilling
Also can be used for water well drilling & core sample drilling
Best choice for your projects.
perforar pozos de agua| perforaciones para agua| perforadoras de pozos| perforacion de pozo profundo| perforacion pozos agua| empresas de perforacion de pozos| venta de equipos de perforacion de pozos de agua
Product Description
Specification
| items | unit | Value | |||
| hole caliber | mm | 400 ~ 1000 | |||
| drilling depth | m | 100 ~ 50 | |||
| Spindle speed | Y225M-6 electric motor | forward | r/min | 47.6; 80; 134; 224; 355; 383 | |
| reverse | 53 | ||||
| Y225S-4 electric motor | forward | 72; 121; 202.5;338; 536; 578.5 | |||
| reverse | 80 | ||||
| Max. spindle output torque | Y225M-6 electric motor | N.m | 6000 | ||
| Y225S-4 electric motor | 4980 | ||||
| spindle push force | kN | 73.5 | |||
| spindle pull force | kN | 98 | |||
| Max. spindle feed stroke | mm | 600 | |||
| lifting force of hoist (with single wire rope) | kN | 39.6 | |||
| retraction distance | mm | 530 | |||
| power unit | Electric | Y225M-6 30 kW 980r/min | |||
| motor | Y225S-4 37 kW 1480r/min | ||||
| overall dimension (L×W×H) | mm | 3030×1250×1935 | |||
| weight (excluding power unit, kelly) | kg | 2200 | |||
| Max. detachable part | kg | 350 | |||
Main Types
1.Core Drilling Machine 2.Water Well Drilling Machine 3.Anchoring Drilling Rig
4.Down-the-hole Drilling Machine 5.Underground Drilling Rig 6.Horizontal Directional Drilling Rig
