Hot sold, efficient truck-mounted water well drilling rig, for geological exploration, building foundation exploration, grouting hole and water well drilling
XYC-200GT
1.APPLICATION
XYC-200GT truck-mounted drilling rig is mainly used for geological general investigation and exploration, road and tall building exploration,kind of hole in concrete structure, river levees, subgrade grouting hole, drilling and direct grouting, civil wellsand earth temperature central air-conditioner, etc.
2.FEATURES
-Hydraulic multi-founctional drilling rig
-Portable drilling rig
-Hoist and mast driven by hydraulic system
3.SPECIFICATION
Technical Specification | |||
Drilling capacity(m) |
30-200 |
||
Hole diameter(mm) |
300-75 |
||
Drilling angle(°) |
90-75 |
||
Rotary speed(r/min) |
64,128,287,557 |
||
Spindle stroke(mm) |
450 |
||
Single lift force(Kg) |
1600 |
||
Wireline capacity(m) |
35 |
||
Lifting speed(r/min) |
17,35,75,151 |
||
Wireline diameter(mm) |
12.5 |
||
Mast height(mm) |
7000 |
||
Drilling Kelly(mm) |
59*53 |
||
Drilling rod(mm) |
42,50,60 |
||
Rig weight(kg) |
1500 |
||
Engine |
Model:ZS1115 diesel |
||
14.7kw/2200rpm | |||
BW-160 Mud pump |
Displacement(L/min) |
160 |
|
Working pressure(Mpa) |
1.3 |
||
Power(kw) |
5.15 |
||
Weight(kg) |
190 |
||
Demensions(mm) |
1110*725*965 |
||
