HGY-200 gold prospecting machine

Specifications

gold prospecting machine
1,Two patents
2,Hydraulic chuck or ball chuck
3,Angle range 0-360
4,Convenient to transport

HGY-200 gold prospecting machine



Brief introduction:



1.50 years professional manufacture

2. Certificate: ISO9001:2008

3. Export to:  Africa, the Middle East, South America, Asia,

                     Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.





Two patents for  HGY-200 gold prospecting machine

 Utility patent for transmission case.

 Design patent for appearance.



Drilling Ability of HGY-200 gold prospecting machine

Drilling depth: 200m

Drill hole diameter: 75mm(46~250mm)

Max successful drilling depth: 427m, 478m with 75mm hole diameter



Features of HGY-200 gold prospecting machine :

1) Good stability and high reliability.

2) Multilevel positive and reverse rotate speed.

3) The complete hydraulic chuck and vertical spindle.

4) Convenient to transport  with the small volume and light weight.

5 )Perfect frame's rigidity ,low center of gravity and good stability.



 Technological Data of HGY-200 gold prospecting machine

Model	Drilling Rig(HGY-200)
Drilling depth( m)	200
Drilling rod diameter.(mm)	Φ50
Head angle range	360
Movable cylinder stroke (mm)	360
Spindle speed( r/min)	Positive rotation rate:60 150 240 340 550 830  Reverse rotation rate: 35 85 135 195 330 480
Spindle hole diameter( mm)	Φ65
Spindle output torque max(N.M)	2140
Spindle stroke(mm)	500
Lifting power max( KN)	50
Driving force max(KN)	37
Lifting speed( m/s)	0.6 2.3 3.4
Lifting capacity(single) max(KN)	20
Steel wire rope diameter (mm)	11
Mode of chuck	Full-hydraulic chuck or ball-type chuck
Weight(power unit excepted)(Kg)	750
Overall dimensions(mm)	1860*800*1400
Diesel engine model	Zs1110 ( 14.7KW)
Electromotor model	Y160L-4 ( 15KW)



Use of  HGY-200 gold prospecting machine :

 for geotechnical investigation, exploring, prospecting, water well drilling;Widely used in the construction of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploring, large diameter boring pile and small diameter diamond core deep hole drilling, etc.
