Help CenterHGY-300 Wire-line Geological Drilling Machine
Related Products
-
HGY-1000 Spindle Geotechnical Investigation Drilling RigUS$ 1 - 2MOQ: 1 Set -
100m Mining Core Drilling MachineUS$ 1 - 2MOQ: 1 Set
-
XUL-100 Soil Sampling Core Drill Rig MachineUS$ 1 - 2MOQ: 1 Set
-
HGY-200 SPT Drilling Rig for Soil TestUS$ 1 - 2MOQ: 1 Set
-
200m Depth Soil Test Drilling Rig for SPT TestUS$ 1 - 2MOQ: 1 Set
Specifications
Drilling depth: 300mDrill dia.: 75mm
Take rock core sample in mining exploration, geological survey
HGY-300 Drilling Rig
It is widely used in the construction of the projects e.g. prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc.
Brief introduction:
1.32 years professional manufacture
2. Certificate: ISO9001:2008
3. Export to: Africa, the Middle East, South America, Asia,
Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.
Features:
1) Wide range of suitable rotary speed to meet various needs.
2) Common auto parts, such as clutch, transmission case and shifting structure.
Application:
1. Coal mining exploration, Ore exploration;
2. Small hole diameter water well drilling;
3. Geothermal pipe-installing for heat pump;
4. Small-diameter hole foundation piling drilling
Technological Data of Drilling Rigs:
Model |
HGY-300 Drilling Rig |
Drilling depth( m) |
300 |
Drilling rod diameter.(mm) |
Φ50 |
Head angle range |
0~360° |
Movable cylinder stroke (mm) |
400 |
Spindle speed( r/min) |
Positive rotation rate:50 87 137 189 230 399 629 868 Reverse rotation rate: 39 180 |
Spindle hole diameter( mm) |
Φ63/Φ95 |
Spindle output torque max(N.M) |
2800 |
Spindle stroke(mm) |
530 |
Lifting power max( KN) |
60 |
Driving force max(KN) |
40 |
Lifting speed( m/s) |
0.41 0.72 1.13 1.6 |
Lifting capacity(single) max(KN) |
30 |
Steel wire rope diameter (mm) |
Φ13 |
Mode of chuck |
hydraulic chuck or pillar-type chuck |
Weight(power unit excepted)(Kg) |
1200 |
Overall dimensions(mm) |
2315*900*1700 |
Diesel engine model |
K4100D(30KW) |
Electromotor model |
Y180L-4( 22KW) |
Our company has produced drilling equipments for 50 years. We have passed ISO9001:2008, TS16949, CE Certification, MA Certification, High-tech Enterprise Certification.
The rigs are widely used in the construction of the projects e. g. prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc. The main products are engineering geological drilling rig;water well drilling rig; vertical shaft 100, 200, 300, 650, 1000, 1500m rigs, full hydraulic power head 1000, 2000m rigs. At the same time, we produce drill bits and drill tools matching with the drilling rigs. Many rigs and drill bits possess patent certificates. Our products have exported to many countries of world. Such as Nepal, India, SriLanka, Afghanistan, Malaysia, Iran, Sudan, Chile etc.
|
|
|
|
|
| Our Factory | our team of foreign trade | In 1992,100m drill in Antarctica in the world | Go to driiing site to train drilling knowledge |
Drill tools for water well
Drill tools for exploration
Drilling tools for wire-line coring:
