Spindle SPT Test Drilling Rig

Spindle SPT Test Drilling Rig thumbnail-1
Spindle SPT Test Drilling Rig photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Hunan Flydisc New Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Diesel
Place of Origin Hunan, China
Brand Name FLYDISC
Model Number HGY-200
Usage Coal
Voltage 220v
Power(W) 15kw
Dimension(L*W*H) 1860*800*1400
Weight 750kg
Certification ce/ISO9001:2008
Warranty 6 months
After-sales Service Provided Overseas service center available

Specifications

HGY-200 SPT test drilling rig
1,Two patents
2,Hydraulic chuck or ball chuck
3,Angle range 0-360
4,Convenient to drill

  HGY-200 soil test drilling rig for SPT test

Company Information

Our company has produced drilling equipments for 50 years. We have passed ISO9001:2008, TS16949, CE Certification, MA Certification, High-tech Enterprise Certification. The rigs are widely used in the construction of the projects e. g. prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc. The main products are engineering geological drilling rig;water well drilling rig; vertical shaft 100, 200, 300, 650, 1000, 1500m rigs, full hydraulic power head 1000, 2000m rigs. At the same time, we produce drill bits and drill tools matching with the drilling rigs. Many rigs and drill bits possess patent certificates. Our products have exported to many countries of world. Such as Nepal, India, Sri Lanka, Afghanistan, Malaysia, Iran, Sudan, Chile etc.



Production

Spindle SPT test drilling rig







Packaging & Shipping

Spindle SPT test drilling rig

 Wooden case package



Product Description
Two patents for  HGY-200 soil testing drilling rig SPT

 Utility patent for transmission case.

 Design patent for appearance.



Drilling Ability of HGY-200 soil test drilling rig SPT

Drilling depth: 100m

Drill hole diameter: 75mm(46~250mm)

Max successful drilling depth: 427m, 478m with 75mm hole diameter



Features of HGY-200 soil testi drilling rig SPT

1) Good stability and high reliability.

2) Multilevel positive and reverse rotate speed.

3) The complete hydraulic chuck and vertical spindle.

4) Convenient to transport  with the small volume and light weight.

5 )Perfect frame's rigidity ,low center of gravity and good stability.



 Technological Data of HGY-200 soil test drilling rig SPT

     Model

Drilling Rig(HGY-200)

Drilling depth( m)

200

Drilling rod diameter.(mm)

  Φ50

 Head angle range

360

Movable cylinder stroke (mm)

360

Spindle speed( r/min)

  Positive rotation rate:60 150 240 340 550 830

Reverse rotation rate: 35 85 135 195 330 480

Spindle hole diameter( mm)

Φ65

Spindle output torque max(N.M)

2140

Spindle stroke(mm)

500

Lifting power max( KN)

50

Driving force max(KN)

37

Lifting speed( m/s)

0.6 2.3 3.4

Lifting capacity(single) max(KN)

20

Steel wire rope diameter (mm)

11

Mode of chuck

Full-hydraulic chuck or ball-type chuck

 Weight(power unit excepted)(Kg)

 750

Overall dimensions(mm)

1860*800*1400

Diesel engine model

Zs1110 ( 14.7KW)

 Electromotor model

Y160L-4 ( 15KW)







Use of HGY-200 soil test drilling rig SPT for geotechnical investigation, exploring, prospecting, water well drilling;

Widely used in the construction of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploring, large diameter boring pile and small diameter diamond core deep hole drilling, etc.



Spindle SPT test drilling rig







Matching Drill Tools

The drill tools for water wellSpindle SPT test drilling rig

The drill tools for geotechical investigation(SPT test)



Spindle SPT test drilling rigSpindle SPT test drilling rig

 Drill tools for  exploration wireline

Spindle SPT test drilling rig

Spindle SPT test drilling rigSpindle SPT test drilling rig
