RichTech -- Ten Points Touch Panel
Introduction
RichTech’s 42’’ touch frame transfers ordinary LCD, LED and projection surface into an amazing multitouch device, which allows a user operates screen with his fingers instead of using a mouse. With its precision touch-tracking and supports up to 32 simultaneous touch inputs, RichTech’s multi-touch frame brings you a fresh experience.
Details:
Features
• Supports 10 touch points (5 fingers gesture supported)
• Communication port: USB 2.0 Full Speed
• Powered by USB; one cable for power or external power supply (Optional)
• Ultra-Low Power Consumption: Operating ≤750mW; Standing by ≤ 250mW
• Extremely low-cost
• Accurate and Reliable
• No Ghost Point
• Drift-free
• Flexible; full mouse functionality with the touch of your finger or any object
• Landscape or Portrait Orientation
• Any touch, finger, gloved hand or pointer
• Calibration; four-points with no drift
• TUIO and Windows multi-touch supported
• Compatible with Windows7,Windows8,Vista,XP,Mac OS,Linux,Android
• Certification of FCC, CE, RoHS, IP65 approved
Specification
Size(inch) |
32’’ 42’’ 46’’ 50’’ 55’’ 60’’ 65’’ 70’’ 80’’ are all available |
Frame Dimension |
19mm width, 10.8mm thick(without glass) |
Luminous transmission |
95-100% typical with clear glass |
Touch technology |
Infrared |
Activation force |
No pressure required |
Resolution |
32767×32767 |
Durability |
Unlimited |
Response Time |
7 - 13ms |
Power supply system |
USB Power supply |
Application
Exihibition:
Advertising:
Entertainment:
More Service
1. Two year warranty
2. 24-hour technical support
More software for free! We could provide you free software applied in the multi-touch screen or multi-touch table.
Installation guide
Step 1: Open the package, take the frames out gently.
Step 2: Remove the ribbon
Step 3: Get rid of the EPE
Step 4: Please check the connector through holes and assemble the frames with HDMI Connector gently. The correct way of assembling should have two same colored arrows together, please don`t twist the HDMI connector.
Step 5: Fasten frames with screws attached for you.
Step 6: Done
Package
About RichTech
RichTech is committed to providing multimedia solutions to customers on a global scale.We have had many experiences in large events, including the World Expo in Shanghai. Customers in more than 90 different countries have benefited from their multimedia services and top-notch customer service. RichTech is at the cutting edge of technology and offers products such as touch systems, virtual reality, multimedia products and interactive projection technologies to customers both large and small.
RichTech has attended a lot exhibitons every year all over the word. We are totally oriented on customer
and claim our aim to build strong partnership.
