DING HUA DH-5860 bga rework station, bga repair machine
Specification for DH-5860 BGA rework station:
Total Power |
4800w |
Top heater |
800W |
Bottom heater |
Second heater 1200W,IR preheating 2700w |
power |
AC220V±10% 50/60Hz |
Dimensions |
L800*W900*H750mm |
Positioning |
HD touch screen, intelligent conversational interface, digital system setting. |
Temperature control |
K Sensor, Closed loop |
Temp accuracy |
±2°C |
PCB size |
Max500*400mm min 22*22mm |
BGA chip |
2X2-80X80mm |
Minimum chip spacing |
0.15mm |
External Temperature Sensor |
1 optional |
Net weight |
48kg |
Pictures for DH-5860 BGA rework station
All kinds size of Titanium alloy nozzles
Features:
- High definition touch screen (Taiwan) , PCL control, can save multiple groups profile, password
- protection and modify function, equipped with instant temperature curve analysis function;
- There are 3 independent heating areas. The 1st and 2nd are hot-air heaters, the 3rd is IR preheating.
- Offer all kinds size of titanium alloy material hot-air nozzles, it can rotate 360°, easy to install and change, customized is available;
- K-type thermocouple (closed loop), heating independently, temperature precision within ± 3degree.
- Vgroove PCB support can be adjusted in any direction with external universal fixture, suitable for all kinds
- of BGA repair.
- Powerful cross,flow fan rapidly cool the PCB board to improve efficiency; prevent the PCB boards
- from deformation.
- Also built-in vacuum pump and external vacuum suction pen, pick up the chips rapidly.
- With 5,10 second voice warning before heating finished. So that you can use the vacuum pen to pick up
- the chips. When the top and bottom heating system finished working, the cooling system
- automatic to begin working, when the temperature the same with the room temp, the cooling
- system stop work automatic, protect the machine old aging.
- CE certificate, with emergency stop button and Automatic power,off protection device when abnormal
- accident happens;with a double overheating protection control.
- Top air flow adjust, you can adjust the top heating wind, suitable for repair all kinds size of chips.
- LED working light, high light and long lifetime.
- With USB port, convenient to download the current curve to save in the U-disk.
- With external universal fixture, protect the PCB boards, suitable for repair any kinds size and
- shape BGA chips, prevent the PCB boards from deformation.
1. The machine can be delivered by DHL, FedEx, TNT, EMS, UPS.
2. By sea or by air. Please provide us your nearest port.
3. The delivery date is within 7 days after the receipt of payment. If you are in urgent need of it,please kindly tell us.
Company profile
Our customer
1) This is the first time I use this kind of machine, is it easy to operate?
There is english manual or guidance that show you how to use machine. Very easy to use it.D
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea.
5) You are a trade company or a manufacturer?
We are a manufacture, with our own skilled R&D department.
6) If i want to visit your factory, will you arrange the pick up and hotel?
Of course, we can arrange everything! only 20 minutes reach Shenzhen airport.
why choose us?
1. We are specialized in BGA rework station,automatic soldring robot, automatic screw locking machine ect more than 6 years,
2. Cooperating with HUAWEI, GREE, SAMSUNG, LG etc well-known brand company.
3. Manufacturer with skilled-engineers.
4. The core components, with premium quality materials, imported from Japan and Germany.
5. Offer high quality before and after-sales service.
6. Delivery on time for decent order.
7. 3 years warranty, the first years for free warranty, the second and third year receive the parts of cost.
8. With CE, ROHS, UL certification approved!
1. Before delivery, the machine will be aging test for 3 days.
2. 3 years warranty. The first year free warranty, the second and third year receive the parts of cost.
3. 3 years warranty for the hearting wire.
